Cellular Modems
The RX1510 can be equipped with cellular modem modules for operation on GSM, EDGE, HSPA+, or CDMA
networks. The cellular modems feature 50 Ω SMA antenna connectors on the front plate of each module. The
following cellular modem modules are available:
Table 13: Cellular Modem Modules
Module Order Code
W11
W12
W21
W22
W32
Figure 62: Single Port Cellular Modem: Antenna Connections
30
Description
1 Port Cell Modem GSM,EDGE,HSPA+
2 Port Cell Modem GSM,EDGE,HSPA+
1 Port Cell Modem EVDO Rev.A Verizon Wireless
2 Port Cell Modem EVDO Rev.A Verizon Wireless
1 Port Cell Modem GSM,EDGE,HSPA+, 1 Port Cell Modem EVDO Rev.A Verizon Wireless
