3. Installation Procedures

3.6.2. SFD Type Base Station

The power system is supplied by the operator.
Connect the power system DC output to the RuggedCom cable with proprietary connector
(supplied by RuggedCom).
Connect the other side (open end) of the RuggedCom cable to the operator's power system
(according to the labelling on the cable and the tables below.
RuggedCom Cable
-48VDC
+48VDC
GND
Table 3.4. +48 VDC Power System
RuggedCom Cable
-48VDC
+48VDC
GND
Table 3.5. -48 VDC Power System
Figure 3.11, "Positive 48V Configuration"
+48V and -48V configurations.
Figure 3.11. Positive 48V Configuration
Figure 3.12. Negative 48V Configuration
RuggedCom® RuggedMAX WiN7000
Power Supply
-48VDC
+48VDC/ GND
-48VDC/ GND
Power Supply
-48VDC
+48VDC/ GND
+48VDC/ GND
and Figure 3.12, "Negative 48V Configuration"
25
Note
GND
"HOT Line"
Connect -48V and GND
Note
"HOT Line"
GND
Connect +48V and GND
show
