3. Installation Procedures
3.4. Installing the WiN7000
The equipment should be installed in compliance with the National Electrical Code
(NEC), ANSI/NFPA 70, the Canadian Electrical Code (CEC), Part 1, CSA C22.1;
and when applicable, the National Electrical Safety Code IEEE C2. Unless marked
or otherwise identified, the Standard for the Protection of Electronic Computer/Data
Processing Equipment, ANSI/NFPA 75.
The following components are required for the installation:
• Mounting bracket
• WiN7000 device
• RF antennas
• GPS antenna
• Power supply
• Ground, data, and power cables
To install the WiN7000 base station, follow these general steps:
1. Install the mounting bracket at the chosen location.
2. Install the antennas.
3. Prepare the grounding cables.
4. Lay out the connection cables.
5. Mount the power supply.
6. Mount the base station to the mounting bracket.
7. Connect all cables to the WiN7000 and seal connections with suitable electrical tape or putty.
RuggedCom® RuggedMAX WiN7000
16
Installation Guide Rev1
