Roberts CR9933 User Manual

Dual alarm clock radio with nightlight
Hide thumbs
Table of Contents

Advertisement

Quick Links

CR9933
Dual Alarm Clock Radio
with Nightlight
Please read this manual before use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CR9933 and is the answer not in the manual?

Questions and answers

Related Manuals for Roberts CR9933

Summary of Contents for Roberts CR9933

  • Page 1 CR9933 Dual Alarm Clock Radio with Nightlight Please read this manual before use...

  • Page 2: Table Of Contents

    Contents Contents ....................................1 Controls ....................................2-4 Switching on and setting the time ............................5 Listening to the radio ................................6 Setting alarm times ................................7-8 Checking the alarm times ............................... 9 Setting the alarms to wake to buzzer ........................... 10 Setting the alarms to wake to radio ............................

  • Page 3: Controls

    Controls (Front) (Top) Night Light Time Snooze Sleep Alarm Set 1. Alarm 2 indicator 6. Time reverse button 11. Time set button 2. Alarm 1 indicator 7. Time forward button 12. Alarm set button 3. Dial pointer 8. Night light button 13.
  • Page 4 Controls (Left side) (Right side) Tuning 16. Headphone socket 19. Volume control 17. Loud Speaker 20. Battery back-up compartment (underside) 18. Tuning control 21. Loud Speaker...

  • Page 5: Controls

    Controls (Back) 22. Waveband selector switch 23. Alarm 1 selector switch 24. Alarm 2 selector switch If you need any further advice, please call our Technical Helpline on :- 020 8758 0338 (Mon-Fri)

  • Page 6: Switching On And Setting The Time

    Switching on and setting the time Before using your clock radio you must first set the correct time. CR 9933 Night Light Dual Alarm 1. Place the unit on a flat surface. Plug the mains lead into a wall socket and switch on.

  • Page 7: Listening To The Radio

    Listening to the radio 1. Switch on the radio by pressing the On button. 2. Select the required waveband using the Waveband selector switch. 3. Tune in to the desired station by rotating the Tuning control. The station frequency is indicated by the Dial pointer. The Wire aerial located on the rear of your clock radio is for FM reception.

  • Page 8: Setting Alarm Times

    Setting alarm times The alarms can be set to wake you by either the buzzer or the radio. Your alarm clock radio has 2 separate alarms which can be set to activate at different times. Setting alarm 1 1. Slide the Alarm 1 selector switch to the preferred buzzer or radio position.

  • Page 9: Setting Alarm 2

    Setting alarm 2 1. Slide the Alarm 2 function switch to the preferred buzzer or radio position. Ensure that the Alarm 1 selector switch is on Off while setting Alarm 2 but remember to switch Alarm 1 back to buzzer/radio after setting alarm 2.

  • Page 10: Checking The Alarm Times

    Checking the alarm times 1. To check the time set on alarm 1, set the Alarm 1 selector switch to the buzzer or radio position. Ensure that the Alarm 2 selector switch is off while checking alarm 1 but remember to reset the alarm 2 selector switch back to buzzer/radio after the check has been completed.

  • Page 11: Setting The Alarms To Wake To Buzzer

    Setting the alarms to wake to buzzer 1. Set the alarm time as previously described. Set the appropriate Alarm selector switch to the 'Buzzer' position. The corresponding Alarm indicators will light. 2. The buzzer alarm will sound every day at the preset time for 59 minutes.

  • Page 12: Snooze Control

    Snooze control Snooze 1. The radio or buzzer alarm can be silenced for 7 minutes by pressing the Snooze button. This sequence can be repeated whilst the alarm is sounding. Sleep timer The radio can be set to switch off after a preset time has elapsed. Sleep 1.

  • Page 13: Dimmer Switch

    Dimmer switch The Dimmer switch located on the underside of your clock radio will allow you to adjust the intensity of the clock display to suit room brightness. Headphone socket (on left hand side) A Headphone Socket (3.5mm) is provided for use with either headphones or an earpiece.

  • Page 14: General

    IF IN DOUBT - CONSULT A QUALIFIED ELECTRICIAN. Mains supply Back-up battery (not necessary for the unit to function) The CR9933 will operate from a supply of AC 230volts, 50Hz only. Slide the battery cover catch in the direction of the arrow. Remove the For your convenience this product is supplied with a plug which is fitted battery cover.

  • Page 15: Specifications

    Specifications Circuit features Power Requirements Loudspeaker 8 ohms Mains AC 230 volts, 50Hz only Back-up Battery IEC size 6F22/06PP (6LR61, PP3) Output power 350mW Frequency Coverage Aerial System Wire Aerial 87.5 - 108MHz 540 - 1600 kHz Built-in Ferrite aerial The Company reserves the right to amend the specification without notice.

  • Page 16: Guarantee

    In the event that it is not possible to return the instrument to the Roberts' dealer from whom it was purchased, please contact Roberts Radio Technical Services at the address shown below. These statements do not affect the statutory rights of a consumer.

This manual is also suitable for:

Pisa one cr9933
