- Page 1 ShoreTel 110 IP Phone Quick Install Guide & Warranty...
-
Page 2: Document And Software Copyrights
ShoreTel, Inc. ShoreTel, Inc. reserves the right to make changes without notice to the specifications and materials contained herein and shall not be responsible for any damage (including consequential) caused by reliance on the materials presented, including, but not limited to, typographical, arithmetic, or listing errors. -
Page 3: Package Contents
Installing Your ShoreTel 110 IP Phone This section shows how to install a ShoreTel 110 IP Phone. Instructions are provided for connecting phones with and without the AC power adapter. (This adapter may be necessary for networks that do not support the IEEE 802.3af standard for Power-over- Ethernet). - Page 4 Attach phone to base Locate the largest of the three tabs Rotate the two pillars toward the on the phone stand and insert this smaller slots and guide the tabs into tab into the slot on the underside of place. the phone.
- Page 5 Connect to powered network (no AC adapter required) If the LAN to which this phone will be connected supports power-over-Ethernet, no AC adapter is needed. The phone draws power from the Ethernet network. Connect the network cable between the LAN port on the back of the phone and an Ethernet jack in the workspace (or on a data switch/router that...
- Page 6 Connect to power & network (Non-powered Ethernet network requires AC power adapter) Connect the second network Connect the AC power cable cable to the DATA IN port** between the on the adapter and an Ethernet jack in the adapter and an electrical socket.
- Page 7 Connect handset For optimal use, attach the longer end of the handset cable to the handset. Connect the short end of the handset cable to the jack on the phone body.
-
Page 8: Important Safety Instructions
Important Safety Instructions For IP TELEPHONE, MODELS 110, 210, 212k, 230, and 560 This symbol is to alert you to important operating or servicing instructions that may appear in this owner’ s manual. Always follow basic safety precautions when using this product to reduce the risk of injury, fire, or electric shock. -
Page 9: Features And Functions
Features and Functions Indicator LED Handset LCD Display Alerts the user to incoming 1 x 16 characters calls and new voice messages. Function Keys Perform core telephony functions. Transfe r Confe r enc e Inte r co m V oice Mai Redial Hold Function Keys overlay... -
Page 10: Warranty And Limitation Of Liability
ShoreTel or its authorized reseller. ShoreTel's sole obligation under this express warranty shall be, at ShoreTel's option and expense, to repair... - Page 11 This ShoreTel IP Phone has been marked with the CE mark. This mark indicates compliance with EEC directories 89/336/EEC and 73/23/EEC. A full copy of the Declaration of Conformity can be obtained from ShoreTel Inc., 960 Stewart Drive,...
- Page 12 ShoreTel® IP is a trademark of ShoreTel, Inc. in the United States, and various countries. Do not remove (or allow any third party to remove) any product identification, copyright, or other notices. The software contained within this product is protected by United States copyright laws and international treaty provisions.
