WARNING: Maintain the
minimum clearanc es
i n F i g u r e 4 . If
provide greater clearances from
floor, ceiling, and joining wall.
Figure 4 -Mounting Clearances As
Viewed From Front Of Heater
FASTENING HEATER TO WALL
Mounting Bracket
The mounting bracket is located
on back panel of heater (see
Figure 5). It has been taped there
for s hipping. Rem ov e m ounting
bracket from back panel.
Figure 5 -Mounting Bracket
Location
INSTALLATION
Removing Lower Front Panel Of
Heater
s hown
1. Remove two screws near
yo u c a n ,
bottom corners of lower front
panel.
2. Pull bottom of lower front panel
forward, then down (see Figure
6).
Figure 6 - Removing Lower Front
Panel Of Heater
Methods For Attaching Mounting
Bracket To Wall
Only use last hole on each end
of mounting bracket to attach
bracket to wall. Attach mounting
bracket to wall only in one of two ways:
1. Attaching to wall stud
2. Attaching to wall anchor
Attaching to Wall Stud: This method
provides the strongest hold. Insert
mounting screws through mounting
brac ket and into wall studs.
7
Attaching to Wall Anchor: This
m ethod allows you
mounting bracket to hollow walls
(wall areas between studs) or to
solid walls (concrete or masonry).
Decide which method
suits your needs. Either method
will provide a secure hold for the
mounting bracket.
Marking Screw Locations
1. Tape mounting bracket to wall
where heater will be located.
Make sure mounting bracket is
level.
WARNING:
minimum clearances shown in
Figure 8. If you can, provide
greater clearances from floor
and joining wall.
2. Mark screw loc ations
wall. (see Figure 7)
Note: Only mark last hole on
each end of mounting bracket.
Insert mounting screws through
these holes only.
3. Remove tape and mounting
bracket from wall.
Figure 7 - Mounting Bracket
Clearances
to attac h
better
Maintain
on
