Garland E22 series Installation Manual

E22 series; e24 series; e18 series; e20 series electric units

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

E22, E24, E18 & E20 SERIES ELECTRIC UNITS

FOR YOUR SAFETY:

DO NOT STORE OR USE GASOLINE

OR OTHER FLAMMABLE VAPORS OR

LIQUIDS IN THE VICINITY OF

THIS OR ANY OTHER

IMPROPER INSTALLATION, ADJUSTMENT,

ALTERATION, SERVICE OR MAINTENANCE

CAN CAUSE PROPERTY DAMAGE, INJURY,

OR DEATH. READ THE INSTALLATION,

OPERATING AND MAINTENANCE

INSTRUCTIONS THOROUGHLY

BEFORE INSTALLING OR

SERVICING THIS EQUIPMENT

Users are cautioned that maintenance and repairs must be performed by a Garland authorized service agent

using genuine Garland replacement parts. Garland will have no obligation with respect to any product that has been

improperly installed, adjusted, operated or not maintained in accordance with national and local codes or installation

instructions provided with the product, or any product that has its serial number defaced, obliterated or removed,

or which has been modified or repaired using unauthorized parts or by unauthorized service agents.

For a list of authorized service agents, please refer to the Garland web site at http://www.garland-group.com.

The information contained herein, (including design and parts specifications), may be superseded and is subject

to change without notice.

GARLAND COMMERCIAL INDUSTRIES

185 East South Street

Freeland, Pennsylvania 18224

Phone: (570) 636-1000

Fax: (570) 636-3903

Part # P66 (01/25/08)

INSTALLATION MANUAL

APPLIANCE

WARNING:

GARLAND COMMERCIAL RANGES, LTD.

1177 Kamato Road, Mississauga, Ontario L4W 1X4

CANADA

Phone: 905-624-0260

Fax: 905-624-5669

PLEASE READ ALL SECTIONS OF THIS MANUAL

AND RETAIN FOR FUTURE REFERENCE.

THIS PRODUCT HAS BEEN CERTIFIED AS

COMMERCIAL COOKING EQUIPMENT AND

MUST BE INSTALLED BY PROFESSIONAL

PERSONNEL AS SPECIFIED.

INSTALLATION AND ELECTRICAL CONNECTION

MUST COMPLY WITH CURRENT CODES:

IN CANADA - THE CANADIAN ELECTRICAL

CODE PART 1 AND / OR LOCAL CODES.

IN USA – THE NATIONAL ELECTRICAL CODE

ANSI / NFPA – CURRENT EDITION.

ENSURE ELECTRICAL SUPPLY CONFORMS WITH

ELECTRICAL CHARACTERISTICS SHOWN ON

THE RATING PLATE.

Enodis UK LTD.

Swallowfield Way, Hayes, Middlesex UB3 1DQ ENGLAND

Telephone: 081-561-0433

Fax: 081-848-0041

Page 1

Table of Contents

Need help?

Do you have a question about the E22 series and is the answer not in the manual?

Questions and answers

Summary of Contents for Garland E22 series

Page 1: Installation Manual
Users are cautioned that maintenance and repairs must be performed by a Garland authorized service agent using genuine Garland replacement parts. Garland will have no obligation with respect to any product that has been improperly installed, adjusted, operated or not maintained in accordance with national and local codes or installation instructions provided with the product, or any product that has its serial number defaced, obliterated or removed, or which has been modified or repaired using unauthorized parts or by unauthorized service agents.
Page 2: Important Information
IMPORTANT INFORMATION WARNING: This product contains chemicals known to the state of california to cause cancer and/or birth defects or other reproductive harm. Installation and servicing of this product could expose you to airborne particles of glass wool/ceramic fibers. Inhalation of airborne particles of glass wool/ceramic fibers is known to the state of California to cause cancer.
Page 3: Table Of Contents
E22 Series Installation Of Banking Plates ........
Page 4: General Information
INSTALLATION 5. Remove lower front panels, by removing the acorn nuts E22 Series Installation Of Banking Plates on each side of the panel. NOTE: CARE SHOULD BE TAKEN WHEN REMOVING LOWER FRONT PANEL, SO THAT THE...
Page 5: Cs22 Counter Stand Installation
Access to the terminal box is gained 4. Connect banking plates as described in E22 Series by removing the 10-24 machine screw and 10-24 hex nut Installation of Banking Plates.
Page 6: Hot Plate - Model E22-12H
INSTALLATION continued Electrical Connection 3. If hydrogenated (solid) frying compound is used, measure 21 lbs (9.5Kg) into the tank. Be sure the heating unit is For supply connection, use wire suitable for 75°C (167°F). completely covered with fat and fat is packed firmly around the heating unit.
Page 7: Sandwich Griddle - Model E22-18Sg
INSTALLATION continued Griddle Thermostats Electrical Connections Griddles are equipped with snap action thermostats. Field For supply connection, use wire suitable for 90°C (194°F). recalibration is seldom necessary and should not be resorted Refer to griddle section for electrical connection, griddle to unless experience with cooking results definitely provides thermostats and calibration instructions.
Page 8: Pizza Ovens - Model E22-22P & E22-22Pp
INSTALLATION continued Controls Pizza Oven Thermostat Infinite switches are used to control the heating units: Pizza ovens are equipped with snap action thermostats. Field recalibration is seldom necessary and should not be resorted to unless experience with cooking results definitely proves Hi to 5 High heat that the control is not maintaining the temperature to which...
Page 9: Hot Plate - Model E24-12H
INSTALLATION continued Controls Broilers Without Splatter Broilers With Guard Splatter Guard Infinite switches are used to control the heating units: Sides 9” (229mm) Sides 3” (76mm) Back 9” (229mm) Back 1” (25mm) Hi to 5 High heat 5 to 3 Medium heat Electrical Connections 3 to Lo...
Page 10: Griddles - Model E24-24G, E24-36G, E24-48G, E24-60G & E24-72G
INSTALLATION continued Griddles – Model E24-24G, E24-36G, Initial Operation E24-48G, E24-60G & E24-72G 1. Before leaving the factory, the fryer was tested and the thermostat calibrated with oil in the fry tank; therefore, it Serial Plate Location is necessary to clean the fry tank before filling with frying The serial plate is located on the grease drawer slide, to compound.
Page 11: Stock Pots Ranges - Model E20-Sp & E20-Spc
INSTALLATION continued Electrical Connections 4. Carefully remove the thermostat dial, not disturbing the dial setting. For supply connection, use wire suitable for 90°C (194°F). 5. Hold the dial shaft steady and with a screw driver, Electrical connection may be made through the knockout at turn the calibration screw located inside the dial shaft, the rear of bottom of the unit to the terminal block, located clockwise to decrease and counter-clockwise to increase...
