INSTALLATION AND OPERATION MANUAL
GARLAND ELECTRIC FRYERS, MODELS: 36ES11, 36ES11SF,
36ES11BL, 36ES11SFBL, 36ET11, 36ST11SF, 36ES21,
36ET21, 680-31F, 680-31SF, 680-31FBL,
FOR YOUR SAFETY:
DO NOT STORE OR USE GASOLINE
OR OTHER FLAMMABLE VAPORS OR
LIQUIDS IN THE VICINITY OF
THIS OR ANY OTHER
IMPROPER INSTALLATION, ADJUSTMENT,
ALTERATION, SERVICE OR MAINTENANCE
CAN CAUSE PROPERTY DAMAGE, INJURY,
OR DEATH. READ THE INSTALLATION,
OPERATING AND MAINTENANCE
INSTRUCTIONS THOROUGHLY
BEFORE INSTALLING OR
SERVICING THIS EQUIPMENT
Users are cautioned that maintenance and repairs must be performed by a Garland authorized service agent
using genuine Garland replacement parts. Garland will have no obligation with respect to any product that has been
improperly installed, adjusted, operated or not maintained in accordance with national and local codes or installation
instructions provided with the product, or any product that has its serial number defaced, obliterated or removed,
or which has been modified or repaired using unauthorized parts or by unauthorized service agents.
For a list of authorized service agents, please refer to the Garland web site at http://www.garland-group.com.
The information contained herein, (including design and parts specifications), may be superseded and is subject
to change without notice.
GARLAND COMMERCIAL INDUSTRIES
185 East South Street
Freeland, Pennsylvania 18224
Phone: (570) 636-1000
Fax: (570) 636-3903
Part # 1009086 (01/31/08)
Part # 19009086 (01/31/08)
680-31SFBL, E24-31F & E24-31SF
APPLIANCE
WARNING:
GARLAND COMMERCIAL RANGES, LTD.
1177 Kamato Road, Mississauga, Ontario L4W 1X4
CANADA
Phone: 905-624-0260
Fax: 905-624-5669
PLEASE READ ALL SECTIONS OF THIS MANUAL
AND RETAIN FOR FUTURE REFERENCE.
THIS PRODUCT HAS BEEN CERTIFIED AS
COMMERCIAL COOKING EQUIPMENT AND
MUST BE INSTALLED BY PROFESSIONAL
PERSONNEL AS SPECIFIED.
INSTALLATION AND ELECTRICAL CONNECTION
MUST COMPLY WITH CURRENT CODES:
IN CANADA - THE CANADIAN ELECTRICAL
CODE PART 1 AND / OR LOCAL CODES.
IN USA – THE NATIONAL ELECTRICAL CODE
ANSI / NFPA – CURRENT EDITION.
ENSURE ELECTRICAL SUPPLY CONFORMS WITH
ELECTRICAL CHARACTERISTICS SHOWN ON
THE RATING PLATE.
Enodis UK LTD.
Swallowfield Way, Hayes, Middlesex UB3 1DQ ENGLAND
Telephone: 081-561-0433
Fax: 081-848-0041
© 2004 Garland Commercial Industries, Inc.
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Garland 36ES11
Summary of Contents for Garland 36ES11
-
Page 1: For Your Safety
Users are cautioned that maintenance and repairs must be performed by a Garland authorized service agent using genuine Garland replacement parts. Garland will have no obligation with respect to any product that has been improperly installed, adjusted, operated or not maintained in accordance with national and local codes or installation instructions provided with the product, or any product that has its serial number defaced, obliterated or removed, or which has been modified or repaired using unauthorized parts or by unauthorized service agents. -
Page 2: Important Information
IMPORTANT INFORMATION WARNING: This product contains chemicals known to the state of California to cause cancer and/or birth defects or other reproductive harm. Installation and servicing of this product could expose you to airborne particles of glass wool/ceramic fibers. Inhalation of airborne particles of glass wool/ceramic fibers is known to the state of California to cause cancer. -
Page 3: Table Of Contents
TABLE OF CONTENTS IMPORTANT INFORMATION......... . 2 SPECIFICATIONS . -
Page 4: Specifications
THREE PHASE NOMINAL AMPERES PER LINE KW PER PHASE TOTAL 208, 240, 460 1 PHASE THREE PHASE MODEL 36ES11 36ES11BL 36ST11 680-31F 58 51 26 33 33 33 30 30 30 15 15 14 680-31FBL E24-31F 36ES11SF 36ES11 SFBL 36ET11SF... -
Page 5: Introduction
C. Body parts dented or scratched? D. Check handles, tops and body paint for rub marks, Thank you for using Garland products. It is our pleasure to scraps. serve you. 3. With carrier driver on your site, note damage on freight Rating Plate bill. -
Page 6: Storage Base Models
INSTALLATION Continued The Garland 36E series complies with the standards CSA 5. Replace F.W.T. box cover and attach with two (2) fasteners. C222 no. 109-latest edition, the UL197-latest edition and the Upon completion of power input supply connection test NSF #4 latest edition. The installation & Connection of this fryer for operation by following the procedure as described appliance must comply with the current codes. -
Page 7: Counter Top/Modular Models - Rated Less Than 48 Amperes
1. Open front cover of the field wiring compartment by removing fasteners. The field wiring compartment is located lower front on 36ES21 models and at rear on 36ES11, E24 (remove tank for front access). OPERATION Preparation Before Use 4. Lift the element handle until the heating elements are in full raised position. -
Page 8: Proper Method Of Filling The Fryer Tank
375 will take over. It will cut off power to the heating elements if degrees F in standard fryers (GARLAND Models: 36ES11, the frying compound reaches a temperature if not less than 36ES11BL, 36ET11, 36ES21, 36ET21, 680-31F, 680-31FBL, 430 degrees F., not more than 450 degrees F. -
Page 9: Cleaning And Maintenance
This booklet provides many basic tips in operating and In either of the above procedures, the heating elements cleaning your GARLAND Fryer. Your supplier of frying should be raised to permit and fluid shortening to drain from compound can provide additional assistance and the elements back into the fryer tank. -
Page 10: Elements
CLEANING AND MAINTENANCE Continued Elements Stainless Steel Advanced design of the special inconnel steel heating Stainless steel should be cleaned using a mild detergent, a elements permits burn-of for easy cleaning. Merely raise soft cloth and hot water. If necessary to use a nonmetallic the elements and heat elements until the soil is burned off.
