Cutsheet for LCi-RTS105/LCi-RTS100
High Performance In-Wall Reference Theater Speakers
LCi-RTS speakers feature an integrated "perfect volume" performance enclosure to ensure superb performance
every time. Because the performance enclosure is the same size as the cutout, the speakers install easily in a post
construction project. An available Stud-Lock Mounting System™ (sold separately) creates a rigid platform increasing
bass performance, clarity and reducing unwanted structure borne vibration. The LCi-RTS105 and the LCi-RTS100 are
®
THX
Ultra 2-certified, so you're assured of great surround sound performance and exceptional dynamic range. The
same driver technologies found in Polk Audio's highly acclaimed LSi and LCi series of freestanding and built-in
speakers are used in the LCi-RTS series.

Hardware (included)

• One LCi-RTS105 speaker
• Speaker mounting template
• Paint mask
• Two grills (one perforated, one cloth)
• Logo Badge
• LCi-RTS105 Manual
• Registration Card
Important Note: If anything is missing or damaged, or if your
LCi-RTS105 speaker fails to operate, notify Polk Audio Installer
Support Services immediately at 800-377-7655.

RTS105 Dimensions

Overall Height
21 7/8" (55.5cm)
Overall Width
12" (30.4cm)
Cutout Height
20 3/8" (51.8cm)
Cutout Width
10 7/8" (27.6cm)
Mounting Depth 3 3/4" (9.65cm)
Available Finish: Paintable White
Cutout
Height
20 3/8"
(51.8cm)
Cutout Width
10 7/8"
(27.6cm)
/
/
w w w . P o l k A u d i o . c o m
8 0 0 . 3 7 7 . 7 6 5 5 ( U S A & C a n a d a )
4 1 0 . 3 5 8 . 3 6 0 0 ( W o r l d w i d e )
Depth measured
from the back of the
enclosure to the
back of the baffle
3 3/4" (9.65cm)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LCi-RTS105 and is the answer not in the manual?

Questions and answers

Summary of Contents for Polk Audio LCi-RTS105

  • Page 1 ® Ultra 2-certified, so you’re assured of great surround sound performance and exceptional dynamic range. The same driver technologies found in Polk Audio’s highly acclaimed LSi and LCi series of freestanding and built-in speakers are used in the LCi-RTS series.
  • Page 2 80HZ-26KHZ Important Note: If anything is missing or damaged, or if EFFICIENCY (2.83V@1M) 92dB EFFICIENCY (2.83V@1M) 92dB your LCi-RTS100 speaker fails to operate, notify Polk Audio >60cm <60cm SPEAKER WEIGHT (INSTALLED) 13 LBS (5.9KG) SPEAKER WEIGHT (INSTALLED) 12.5 LBS (5.7KG) NORM.
  • Page 3 ™ creates a rigid platform for the Toggle to the “normal” position and the Wall Distance Toggle to LCi-RTS105 and RTS100, increasing bass performance, clarity and the greater than 2' (>2) position. reducing unwanted structure borne vibration. The installation inst- ructions supplied with each Stud-Lock Mounting System ™...
