GRAND BAY 40 DIRECT VENT FREESTANDING GAS STOVE
CAUTION!
PRIOR TO FIRST FIRE:
WARNING
If the information in this manual is not followed exactly a fire
or explosion may result, causing property damage, personal
injury or death.
FOR YOUR SAFETY
WHAT TO DO IF YOU SMELL GAS
WARNING
Part #250-3681 #842-2550

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Grand Bay 40 and is the answer not in the manual?

Questions and answers

Related Manuals for Quadra-Fire Grand Bay 40

Summary of Contents for Quadra-Fire Grand Bay 40

  • Page 1 North America’s Best GRAND BAY 40 DIRECT VENT FREESTANDING GAS STOVE CAUTION! PRIOR TO FIRST FIRE: WARNING If the information in this manual is not followed exactly a fire or explosion may result, causing property damage, personal injury or death.
  • Page 2 Grand Bay 40 Direct Vent Freestanding TABLE OF CONTENTS January 2000 Page 2...
  • Page 3 Grand Bay 40 Direct Vent Freestanding GBDV-40 SAFETY LABEL January 2000 Page 3...

  • Page 4: Safety Notices

    Grand Bay 40 Direct Vent Freestanding SAFETY NOTICES WARNING: January 2000 Page 4...

  • Page 5: Specifications

    Grand Bay 40 Direct Vent Freestanding SPECIFICATIONS GAS LINE CONNECTION PRESSURE TESTING NOTE: DIQVUÃTD9@Ã U@TUÃW 6GW@ PVUQVUÃTD9@Ã U@TUÃW 6GW@ January 2000 Page 5...
  • Page 6 Grand Bay 40 Direct Vent Freestanding DIMENSIONS   PP   PP  PP     PP PP   PP   PP   PP   PP GLDPHWHU 'XUD9HQW SLSH   PP   PP ...

  • Page 7: Clearances To Combustibles

    Grand Bay 40 Direct Vent Freestanding CLEARANCES TO COMBUSTIBLES HEARTH REQUIREMENTS January 2000 Page 7...

  • Page 8: High Altitude Operation

    Grand Bay 40 Direct Vent Freestanding HIGH ALTITUDE OPERATION UNPACKING THE STOVE GAS VALVE LOCATION %27720 *5,// January 2000 Page 8...

  • Page 9: Door Installation Instructions

    Grand Bay 40 Direct Vent Freestanding DOOR INSTALLATION INSTRUCTIONS DO NOT USE A HAMMER OR ANY OTHER TOOL. DO NOT HIT THE GLASS. DOOR OPEN DOOR LATCHED Door Retention Latch Bolt Chain in Place A Door Latch January 2000 Page 9...

  • Page 10: Brick Installation

    Grand Bay 40 Direct Vent Freestanding BRICK INSTALLATION Brick Brick Retainer Retainer Brick A Brick B Brick E Manifold Front Log Support Brick C Brick D Manifold Holder BRICK RETAINER TAB January 2000 Page 10...
  • Page 11 Grand Bay 40 Direct Vent Freestanding INSTALLING THE LOG SET CENTERING PINS SHUTTER CERAMIC January 2000 Page 11...

  • Page 12: Thermostat Installation

    Grand Bay 40 Direct Vent Freestanding THERMOSTAT INSTALLATION OPTIONAL THERMOSTATS Thermostat Connection Block RECOMMENDED MAXIMUM LEAD Power Cord LENGTH (TWO WIRE) WHEN USING WALL THERMOSTAT/SWITCH REMOTE CONTROL BLOWER POWER CORD WARNING January 2000 Page 12...

  • Page 13: Gas Connections

    Grand Bay 40 Direct Vent Freestanding INSTALLATION PROCEDURES GAS CONNECTIONS January 2000 Page 13...

  • Page 14: Venting Instructions

    Grand Bay 40 Direct Vent Freestanding VENTING INSTRUCTIONS IMPORTANT INSTALLATION PRECAUTIONS SAFETY PRECAUTIONS FOR THE INSTALLER January 2000 Page 14...

  • Page 15: Simpson Dura-Vent Parts List

    Grand Bay 40 Direct Vent Freestanding SIMPSON DURA-VENT PARTS LIST ° ° ° January 2000 Page 15...

  • Page 16: General Maintenance

    Grand Bay 40 Direct Vent Freestanding SIMPSON DURA-VENT PARTS LIST (cont.) ° ° ° GENERAL MAINTENANCE January 2000 Page 16...
  • Page 17 Grand Bay 40 Direct Vent Freestanding VENTING January 2000 Page 17...

  • Page 18: Planning Your Installation

    Grand Bay 40 Direct Vent Freestanding PLANNING YOUR INSTALLATION *USA installations only January 2000 Page 18...
  • Page 19 Grand Bay 40 Direct Vent Freestanding W@SUD86GÃU@SHDI6UDPI TUPSHÃ8PGG6S (ÃÃ@G7PX AG6TCDIB QDQ@ÃG@IBUC CPSDaPIU 6GÃ U@SHDI6UDPI X 6GGÃUCDH7G@ ADS@TUPQ TVQQPSUÃ7PY QDQ@ÃG@IBUC QDQ@ÃG@IBUC QDQ@ÃG@IBUC 6QQGD6I8@Ã696QU@SÃ DI8GV9@9ÃXTUPW@ QDQ@ÃG@IBUC 6QQGD6I8@Ã696QU@S FIG. 2 FIG. 1 HIGH WIND TERMINATION CAP TERMINATION CAP TOP ADAPTER TOP ADAPTER FLASHING...
  • Page 20 Grand Bay 40 Direct Vent Freestanding HOW TO USE VENT GRAPH ° ° January 2000 Page 20...

  • Page 21: Horizontal Installation

    Grand Bay 40 Direct Vent Freestanding HORIZONTAL INSTALLATION FIG. 5 January 2000 Page 21...
  • Page 22 Grand Bay 40 Direct Vent Freestanding HORIZONTAL INSTALLATION (cont.) &(17(5 2) +2/( &(17(5 /,1( &(17(5 /,1( FIG. 6 January 2000 Page 22...
  • Page 23 Grand Bay 40 Direct Vent Freestanding HORIZONTAL INSTALLATION (cont.) FIG. 7 FIG. 8 January 2000 Page 23...
  • Page 24 Grand Bay 40 Direct Vent Freestanding HORIZONTAL INSTALLATION (cont.) FIG. 9 FIG. 10 January 2000 Page 24...

  • Page 25: Vertical Terminations

    Grand Bay 40 Direct Vent Freestanding VERTICAL TERMINATIONS USING GS SERIES PIPE FIG. 12 FIG. 11 "Ã( #€ H6YDHVH FIG. 13 January 2000 Page 25...
  • Page 26 Grand Bay 40 Direct Vent Freestanding VERTICAL TERMINATIONS (cont.) USING GS SERIES PIPE (cont.) FIG. 14 January 2000 Page 26...
  • Page 27 Grand Bay 40 Direct Vent Freestanding VERTICAL TERMINATIONS (cont.) USING GS SERIES PIPE (cont.) FIG. 16 FIG. 15 January 2000 Page 27...

  • Page 28: Cathedral Ceiling Installation

    Grand Bay 40 Direct Vent Freestanding VERTICAL TERMINATIONS (cont.) CATHEDRAL CEILING INSTALLATION FIG. 18 FIG. 19 January 2000 Page 28...
  • Page 29 Grand Bay 40 Direct Vent Freestanding VERTICAL TERMINATIONS (cont.) INSTALLATION INTO A CLASS A METAL CHIMNEY FIG. 20 FIG. 22 FIG. 21 SHEET METAL SCREWS January 2000 Page 29...
  • Page 30 Grand Bay 40 Direct Vent Freestanding VERTICAL TERMINATIONS (cont.) INSTALLATION INTO AN EXISTING MASONRY CHIMNEY FIG. 23 FIG. 24 January 2000 Page 30...
  • Page 31 Grand Bay 40 Direct Vent Freestanding VERTICAL TERMINATIONS (cont.) INSTALLATION INTO AN EXISTING MASONRY CHIMNEY (cont.) FIG. 25 TOP ADAPTER FIG. 26 January 2000 Page 31...
  • Page 32 Grand Bay 40 Direct Vent Freestanding VERTICAL TERMINATIONS (cont.) INSTALLATION INTO AN EXISTING MASONRY CHIMNEY (cont.) FIG. 27 FIG. 28 January 2000 Page 32...

  • Page 33: Lighting Instructions

    Grand Bay 40 Direct Vent Freestanding LIGHTING INSTRUCTIONS (LOCATED BEHIND PEDESTAL ACCESS DOOR) · · · · · · January 2000 Page 33...

  • Page 34: First Fire

    Grand Bay 40 Direct Vent Freestanding FIRST FIRE January 2000 Page 34...

  • Page 35: Maintenance

    Grand Bay 40 Direct Vent Freestanding MAINTENANCE January 2000 Page 35...
  • Page 36 Grand Bay 40 Direct Vent Freestanding SCHEMATICS January 2000 Page 36...

  • Page 37: Blower And Snap Disc Replacement

    Grand Bay 40 Direct Vent Freestanding BLOWER AND SNAP DISC REPLACEMENT OCATION LOWER OCATION TI6QÃ9DT8 QPX@SÃ8PS9 7GPX@S S@6SÃPAÃTUPW@ January 2000 Page 37...

  • Page 38: Troubleshooting

    Grand Bay 40 Direct Vent Freestanding TROUBLESHOOTING January 2000 Page 38...

  • Page 39: Service Parts

    Grand Bay 40 Direct Vent Freestanding ACCESSORIES SERVICE PARTS January 2000 Page 39...
