About the control panel
GEAppliances
Q
Settings
Individual settings for dryness level (Level), temperature (Temp),and Timed Dry cycle minutes (Time) can be set from
the minimum (lowest in column) to maximum (highest in column). In general, the higher up the column, the more
energy will be used.
Dryness Level-Selection
only used for Sensor cycles. Timed cycles run for the selected time.
Extra Dry
Usefor heavy-duty fabrics or itemsthat should be very dry, such astowels.
More Dry
Use for heavy-duty or mixed type fabrics.
Dry
Use for a normal dryness level suitable for most loads. This isthe preferred cycle for energy savings.
Less Dry
Use for lighter fabrics.
Damp
For leaving items partially damp.
Temperature
High
For regular to heavy cottons.
NOTE:Steam Dewrinkle and Steam Refresh require the High temperature setting.
Medium
For synthetics, blends, delicates and items labeled permanent press.
Low
For delicates, synthetics and items labeled tumble drg low.
Extra Low
For delicates, synthetics and items labeled tumble drg low.
No Heat
For fluffing items without heat. For use only with the Timed Dry cycles.
@
®
@
0
My Settings
(on some models)
Asthe cycle selector knob is turned, the Level (DrynessLevel),Tamp (Temperature)and Time (Timed Dry) settings change to
automatic pre-set default settings. If you desire a different setting, press the appropriate pad(s).Then press and hold the My
Settings pad for 3 seconds and the dryer will "remember" these settings for that Knob Selection. In the future, when you turn
the selector knob to that cycle, your settings will be automatically recalled. NOTE;Signal volume cannot be set for My Settings.
Power
Press to "wake up" the display. If the display is active, press to put the dryer into idle mode.
NOTE: Pressing Power does not disconnect the appliance from the power supply.
Start
PressStart to begin the cycle. NOTE:The door must be closed for the dryer to start the cycle. PressingStart again will Pause
the cycle and the cgcle Indicator Light will blink.
To continue the cycle, press Start again. To stop the cycle, hold the pad for 3 seconds.
eDrg (on some models)
When the eDry pad is pressed,cycle settings change to reduce the total energy consumption of the selected sensor cycle.
NOTE:Cgcle times will change when eDry is selected.
Display Ionsomemodels)
The display shows the approximate time remaining until the end of the cycle.
In addition, this displag will, "scroll" the drger status:
• PAUSE
The message "PAUSE"will scroll across the display when the dryer's cycle is paused. The cycle may be
re-started by pressing the Start pad.
• door
The message "door" will be displayed when the door is opened during the dryer's cycle.
The eMonitor lights display the relative energy use of your selected cycle and options. They are provided as an energy guide
and range from Good (1 light) to Better (5 lights).Cycle (time),dryness level,temperature, and additional tumble options can
increase or decrease your energy efficiency. Some special cycles will not provide a display.
Indicator
lights
Five LEDlights indicate the current dryer status moving from left to right as the cycle progresses.
DSM Demand Side Management (on some models) - When connected to your power company's rate monitoring system, the
dryer will automatically delay starting if the rates are high/critical. An "ES"will be displayed and the selected cycle will
start after/4 hours or when the rates drop to low/medium, whichever comes first. If the rates are not high/critical, the
selected cycle will start immediately.
7
