Generac Portable Products S E10000 Generator
Yourgenerator requires someassembly a ndis ready
foruseafterit hasbeenproperly serviced withthe
recommended oilandfuel.
If you
have any problems with the assembly of
your generator, please call the generator helpline
at 1-800-270-1408.
IMPORTANT: Any attempt to run the engine before it
has been serviced with the recommended oil witl
result in an engine failure.
REMOVE GENERATOR
FROM CARTON
• Set the palteted carton on a rigid flat surface.
• Carefully cut bands around the shipping carton.
• Lift carton off the generator,
• Remove all packing material, carton fillers, etc.
• Remove the generator from the shipping pallet.
CARTON CONTENTS
Check all contents. If any parts are missing or
damaged, call the generator helpline at
1-800-270-1408 Contents include:
10,000 watt generator
Generator owner's manual
Engine owner's manual
2 Bottles of SAE 30 engine oit (28 oz.)
Oit fill spout
125 Volt, 30 Amp plug
125 Volt, 20 Amp plug
120/240 Volt, 30 Amp plug
Wheel kit
CHECK BATTERY / ATTACH
NEGATIVE BATTERY WIRE
The battery on the generator is fully charged, sealed
and pre-installed except for the negative (black)
battery cable.
To install:
• Remove nut on the negative battery terminal.
• Slide the negative battery cable over the screw on
the terminal (Figure 2).
• Reattach nut and tighten.
• Ensure the connections to the battery and generator
are tight and secure.
