IMPORTANT:
Please
read this bulletin and
pass on to others in your
organisation.
New Model Introduction - DEIX2, DGIX2
MARKETS:
USA
MODELS:
DEIX2, DGIX2
PRODUCT CODES: 96105-A, 96105-B, 96106-A, 96016-B
We are pleased to announce the release of the large capacity Intuitive™ top-loading electric dryer into the American market.
The Intuitive Dryer incorporates the functionality of the SmartLoad™ dryer with the flexibility of the Intuitive™ control panel.
Control Panel
Diagnostics / Service Manual
Attached is a copy of the Service Summary that is located inside the console with each machine. We have now combined both
the SmartLoad™ and the Intuitive™ dryer into one document.
The supplementary service manual, part no. 517762, is available on CoolBlue World on the Fisher & Paykel website.
Spare parts
The parts manuals are now also available on CoolBlue World.
DEIX2
96105-A
DEIX2
96105-B
DGIX2
96106-A
DGIX2
96106-B
Note: It is important when locating a spare part from the parts manual, that the complete product code including the
suffix letter is used.
Fisher & Paykel Appliances Ltd
78 Springs Road, East Tamaki, PO Box 58-732, Greenmount,
Auckland, New Zealand, Ph: 09 273 0600, Fax: 09 273 0656
Fisher & Paykel Customer Services Pty Ltd
A.C.N. 003 3335 171, 19 Enterprise Street, Cleveland, QLD 4163
PO Box 798, Cleveland, QLD 4163, Ph: 07 3826 9100, Fax: 07 3826 9164
Fisher & Paykel Appliances
150 Ubi Avenue 4, Sunlight Building #02-00, Singapore 408825
Ph: 6547 0100, Fax: 6547 0123
Fisher & Paykel Appliances Inc
5800 Skylab Road, Huntington Beach, California, CA92647, USA
Ph: 888 936 7872 (F&P), Ph: 888 396 2665 (DCS)
Fisher & Paykel Appliances Ltd UK
Pheasant Oak Barn, Hob Lane, Balsall Common, Warwickshire, CV7 7GX, UK
Ph: 44 1676 531 770, Fax: 44 1676 531 771
DRYERS
NZ = New Zealand
AU = Australia
ROW = International Markets
USA = United States of America & Canada
GB or UK = Great Britain & Ireland
EU = Europe
TW = Taiwan
JP = Japan
KR = Korea
Copyright © Fisher & Paykel 2005. All rights reserved.
DR027
OCTOBER 2005
