4" TILE SAW WITH WET TRAY
SET up And OpERATIng InSTRucTIOnS
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MAnuAL.
©
Copyright
2002, 2009 by Harbor Freight Tools
any artwork contained herein may be reproduced in any shape or form without the express written
consent of Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due
to continuing improvements, actual product may differ slightly from the product described herein.
For technical questions or replacement parts, please call 1-800-444-3353.
Revised Manual 09l
Model
Please Note: Diamond Blade not included, sold separately.
3733
®
. All rights reserved. No portion of this manual or

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3733 and is the answer not in the manual?

Questions and answers

Terry Scott
February 8, 2025

There is a small strip next to the removable table that has the slot that the saw blade sips through. It has three small screws and removing those screws to clean do not free it to be removed. With much effort I can lift it up and clear the 3 screw posts, but it still cannot be removed. It is now at about a 45 degree angle to the table, somewhat loose with seemingly 3 tabs into the other side (the non-removable table) keeping it from removal. Now I cannot put it back into place to return the screws and use the tile saw. How do I get it back in place?

User image 67a7a7dc13db5

Subscribe to Our Youtube Channel

Summary of Contents for Drill Master 3733

  • Page 1 Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improvements, actual product may differ slightly from the product described herein.
  • Page 2: Important Safety Information

    SKU 3733 For technical questions, please call 1-800-444-3353. Page 2...
  • Page 3 Always plication. The correct power tool will wear AnSI-approved eye protec- SKU 3733 For technical questions, please call 1-800-444-3353. Page 3...
  • Page 4: Vibration Safety

    Wear suitable gloves to reduce the account the working conditions vibration effects on the user. and the work to be performed. Use of the power tool for operations differ- SKU 3733 For technical questions, please call 1-800-444-3353. Page 4...
  • Page 5: Specific Safety Warnings

    Tile Saw. These carry important dry or wet ceramic tile, quarry tile, information. If unreadable or miss- marble, terra-cotta, and slate with ing, contact Harbor Freight Tools for a a maximum thickness 1-1/16”. replacement. do not use the Tile Saw for cutting use the right product for the right metals or for cutting curves.
  • Page 6 Saw Blade to stop on its own if the when necessary while in use and Saw Blade is to be backed out of rinse out the Tub after every use. an uncompleted cut. SKU 3733 For technical questions, please call 1-800-444-3353. Page 6...
  • Page 7 Make sure the tile to be cut off has WARnIng! The warnings and cau- sufficient room to move sideways. tions discussed in this manual can- not cover all possible conditions and SKU 3733 For technical questions, please call 1-800-444-3353. Page 7...
  • Page 8: Safety Warnings

    Anyone do not attempt to free a stalled entering the work area must wear blade without turning the Tile Saw personal protective equipment. SKU 3733 For technical questions, please call 1-800-444-3353. Page 8...
  • Page 9 [to the State of california] to cause can- cer, birth defects or other repro- ductive harm. Some examples of SKU 3733 For technical questions, please call 1-800-444-3353. Page 9...
  • Page 10: Grounded Tools: Tools With Three Prong Plugs

    Inc., the Canadian Standard properly grounded outlet. If the tool Association, and the National Electri- should electrically malfunction or cal Code. (See Outlets for 2-Prong break down, grounding provides a Plug.) SKU 3733 For technical questions, please call 1-800-444-3353. Page 10...
  • Page 11: Extension Cords

    “W-A” (“W” in Canada) to (RPM) indicate it is acceptable for outdoor use. Make sure the extension cord is prop- erly wired and in good electrical con- dition. Always replace a damaged SKU 3733 For technical questions, please call 1-800-444-3353. Page 11...
  • Page 12: Specifications

    If assembly. any parts are missing or broken, please call Harbor Freight Tools at the number Remove the Screw (16) that holds shown on the cover of this manual as soon the Table (1) in place and left the as possible.
  • Page 13 Nut (37) Outer Flange (36) FIguRE 3 Arrow Points To FRONT of Tile Saw Remove Screw (16) Outer Flange (36) to Remove Table (1) Nut (37) 4” Blade (Not Included) SKU 3733 For technical questions, please call 1-800-444-3353. Page 13...
  • Page 14: Tool Set Up

    The work area must not rect tool for your application. The allow access by children or pets to prevent injury and distraction. SKU 3733 For technical questions, please call 1-800-444-3353. Page 14...
  • Page 15: General Operating Instructions

    Power Switch (4) to its “OFF” position and unplug the Power Cord (11) from its electrical outlet. To Make Beveled Cuts: Remove the Screw. Then, remove the Table from the Tile Saw unit. FIguRE 4 SKU 3733 For technical questions, please call 1-800-444-3353. Page 15...
  • Page 16: Maintenance And Servicing

    Rip Fence (7), and slowly feed problem corrected before the workpiece into the Blade. further use. When finished making the beveled cut, turn the Power Switch to its OFF” SKU 3733 For technical questions, please call 1-800-444-3353. Page 16...
  • Page 17: Cleaning, Maintenance, And Lubrication

    Not enough water Add proper amount of water Running with hot/warm water Always run with cold water Follow all safety precautions whenever diagnosing or servicing the tool. disconnect power supply before service. SKU 3733 For technical questions, please call 1-800-444-3353. Page 17...
  • Page 18: Parts List

    AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. SKU 3733 For technical questions, please call 1-800-444-3353. Page 18...
  • Page 19: Assembly Diagram

    If product has no serial number, record month and year of purchase instead. note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts SKU 3733 For technical questions, please call 1-800-444-3353. Page 19...
  • Page 20: Limited 90-Day Warranty

    LIMITEd 90 dAY WARRAnTY Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this prod- uct is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
