Page 1: User Manual
Kramer Electronics, Ltd. Preliminary USER MANUAL Model: 123Vxl Differential Video Line Amplifier... -
Page 2: Table Of Contents
Contents Contents Introduction Getting Started Overview Quick Start Your Differential Video Line Amplifier Connecting the 123Vxl Differential Video Line Amplifier Connecting Differential Video Line Amplifier Units Technical Specifications Figures Figure 1: 123Vxl Differential Video Line Amplifier Figure 2: Connecting the 123Vxl Differential Video Line Amplifier Figure 3: Connecting 123Vxl Differential Video Line Amplifier Units Tables Table 1: 123Vxl Differential Video Line Amplifier Features... -
Page 3: Introduction
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products 2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com 3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com... -
Page 4: Overview
Warning – Disconnect power and unplug unit from wall before installing or removing device or servicing unit. 1 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com 2 For example, part number 22535-000251 KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 5: Quick Start
Overview Quick Start This quick start chart summarizes the basic setup and operation steps. -
Page 6: Your Differential Video Line Amplifier
1 For looping select Hi-Z 2 Connects to the CV IN connector on the next unit 3 Insert a screwdriver into the hole and carefully rotate it, to trim the level KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 7: Connecting The 123Vxl Differential Video Line Amplifier
Connecting the 123Vxl Differential Video Line Amplifier Connecting the 123Vxl Differential Video Line Amplifier To connect the 123Vxl, as the example in Figure 2 illustrates, do the following: 1. Connect the video source (for example, a video player) to the CV IN BNC connector. -
Page 8: Connecting Differential Video Line Amplifier Units
Connect the OUT 1, OUT 2 and OUT 3 BNC connectors on the fifth unit to the video acceptors 13, 14 and 15, respectively 3 Use a screwdriver to carefully rotate the trimmer, adjusting the appropriate level KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 9: Technical Specifications
Technical Specifications Technical Specifications Table 2 includes the technical specifications: Table 2: Technical Specifications of the 123Vxl Differential Video Line Amplifier INPUTS: 1 looping video, differential, 1Vpp/75 on a BNC connector OUTPUTS: 3 video, 1Vpp/75 on BNC connectors MAX. OUTPUT LEVEL: 1.7Vpp BANDWIDTH (-3dB): 425MHz DIFF. - Page 10 EXCLUSION OF DAMAGES The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall not be liable for: 1. Damage to other property caused by defects in this product, damages based upon inconvenience, loss of use of the product, loss of time, commercial loss;...
