Front Panel
# Feature
1 YC
2 CV
INPUT
3 UXGA
SELECT
4 HDMI
OR
5 USB
Buttons
6 COMP
7 POWER Switch
8 IR Receiver/LED
9 FREEZE Button
10 PIP Button
11 MENU Button
12 ENTER Button
13 - Button
14 + Button
15 DOWN Button
16 UP Button
17 USB Connector
18 OSD ON Button
19 LCD Status Display
Function
Selects one of the s-Video (Y/C) sources (from 1 to 4)
Selects one of the CV sources (from 1 to 4)
Selects one of the UXGA sources (from 1 to 4)
Selects one of the HDMI sources (from 1 to 4)
Press to select the USB source
JPEG files on a USB memory stick, up to a maximum size of 2048x1536
Selects one of the component video sources (from 1 to 4)
Illuminated switch for turning the unit ON or OFF
Green when ON; red when OFF
OFF in this case means that the outputs and the front-panel are disabled
Freezes the output video image
Applicable to the Scaler outputs only
Selects the picture-in-picture function (see
Displays the OSD Menu screen (or returns to the previous level in the OSD screen)
Moves to the next level in the OSD screen
Press for about 3 seconds to lock/unlock the front panel buttons
Decreases the range by one step
Increases the range by one step
Moves down one step (in the same level) in the OSD screen
Moves up one step (in the same level) in the OSD screen
Connect to a USB drive to read JPEG files
Activates/deactivates access to the OSD Menu
The OSD ON front panel button is activated (illuminated) by default, and pressing the MENU front panel
button (or the MENU key on the infrared remote control transmitter (see
Menu. To prevent OSD display, press the OSD ON front panel button (or the OSD key). The front panel
button no longer illuminates, and the front panel LCD now operates independently of the OSD (when the
OSD is OFF, the LCD is still operational)
Displays the status
Section 6.4 )
Figure 29)) displays the OSD
