Summary of Contents for Kogan KGNPAC34VAA
- Page 1 KGNPAC34VAA USER MANUAL...
-
Page 2: Table Of Contents
CONTENT Important Safeguards Description Preparing For Use Description Of The Control Panel Operating From The Control Panel Description Of The Remote Control Correct use Using The Remote Control Unit Self-diagnosis Tips For Correct Use Cleaning Start - End Of Season Operations Troubleshooting Technical Specifications... -
Page 3: Important Safeguards
IMPORTANT SAFEGUARDS Use this appliance only as described in this instruction manual. As with all electrical equip- ment, whilst the instructions aim to cover as many eventualities as possible, caution and common sense should be applied when operating and installing this appliance. This appliance is designed for home air conditioning and must not be used for other pur- poses It is dangerous to modify or alter the characteristics of the appliance in any way. -
Page 4: Electrical Connections
Important information for correct disposal of the product in accordance with EC Directive 2002/96/EC. At the end of its working life, the product must not be disposed of as urban waste. It must be taken to a special local authority differentiated waste collection centre or to a dealer providing this service. -
Page 5: Description
DESCRIPTION Air outlet grille Control panel Castors Handles Remote control receiver Filter Intake grille Air exhaust hose housing Condensate drain Power cable 11 Flange Cap 12 Air exhaust hose 13 Window outlet 14 Suckers 15 Castor locks 16 Remote control 17 Window bracket COOL SPEED... -
Page 6: Preparing For Use
PREPARING FOR USE The instructions below will enable you to prepare your air condi- tioner for operation as efficiently as possible. Before use, make sure the air intake and outlet grilles are unob- structed. AIR-CONDITIONING WITHOUT INSTALLATION Just a few simple steps and your comfort is ensured with your appliance: Fit the air exhaust hose in the housing at the back of the appliance (fig. - Page 7 AIR-CONDITIONING WITH INSTALLATION If required, your appliance can also be installed semi-perma- nently (Fig. 5). Proceed as follows: Drill in an outside wall or in the window pane a 134 mm dia. hole respecting the heights shown in fig.6. 30 cm 30 cm in the window pane Fit the flange accessory provided in the hole following the...
-
Page 8: Description Of The Control Panel
DESCRIPTION OF THE CONTROL PANEL MOOD ON/OFF MODE POWERFUL TEMP + TEMP - 4 SMART s ymbol 1 Cool symbol 10 Sleep symbol 2 Dry symbol 11 AUTO FAN indicator 3 Fan s ymbol 12 Speed indicator 13 MODE button (selects the modes) 4 HEAT s ymbol 14 POWERFUL button 5 POWERFUL symbol... -
Page 9: Cool Mode
COOL MODE Ideal for hot muggy weather when you need to air conditioning and dehumidify the room. To set this mode correctly: Press the MODE button a number of times until the COOL symbol appears. Select the target temperature by pressing the button until the corresponding value is displayed. -
Page 10: Heat Mode
Maximum speed: for maximum fan power Medium speed: reduces noise levels but still maintains a good level of comfort Low speed: for silent operation In this mode, AUTO speed cannot be selected. HEAT MODE Press the MODE button a number of times until the heating Symbol appears. -
Page 11: Description Of The Remote Control
DESCRIPTION OF THE REMOTE CONTROL Mode indicator Selected temperature scale indicator Signal transmission Auto fan speed indicator Fan symbol COOL COOL SPEED SPEED AUTO QUIET AUTO QUIET POWERFUL POWERFUL Sleep indicator ℃ ℃ SWING SWING SMART SMART Powerful indicator DELAY DELAY DELAY DELAY... -
Page 12: Using The Remote Control Unit
NSERTING OR REPLACING THE BATTERIES Remove the cover on the rear of the remote control; Insert two R03 "AAA" 1.5V batteries in the correct position (see instructions inside the battery compartment); Replace the cover. If the remote control unit is replaced or disposed of, the batte- ries must be removed and discarded in accordance with cur- rent legislation as they are harmful to the environment. - Page 13 17 18 SLEEP FUNCTION This function is useful for the night as it gradually reduces operation of the appliance. To set this function correctly: Select the operating mode (cool, dry or smart) as described above. Press the SLEEP button. The appliance operates in the previously selected mode.
-
Page 14: Self-Diagnosis
Programming shutdown 20 21 Press the TIMER button. The shutdown time and message " " flash on the remote control display . Press the buttons to set the time you want the appliance to shut down (from 1hour to 12 hours). -
Page 15: Tips For Correct Use
TIPS FOR CORRECT USE To get the best from your air conditioner, follow these recom- mendations: Close the windows and doors in the room to be air conditio- ned (fig. 22). When installing the air conditioner semi-per nently, you should leave a door slightly open (as little as 1 cm) close close to guarantee correct ventilation. -
Page 16: Cleaning
CLEANING Before cleaning or maintenance, turn the appliance off by pres- sing the button on the control panel or ON/OFF botton on remote control, wait for a few minutes then unplug from the mains socket. CLEANING THE CABINET You should clean the appliance with a slightly damp cloth then dry with a dry cloth. -
Page 17: Troubleshooting
TROUBLESHOOTING PROBLEM CAUSE SOLUTION The air conditioner there is no current wait does not come on it is not plugged into the mains plug into the mains the internal safety device has ait 30 minutes, if the problem persists, contact your service cen- tripped ter. -
Page 18: Technical Specifications
TECHNICAL SPECIFICATIONS Mains voltage see rating label Maximum absorbed power in air conditioning Refrigerant Cooling capacity LIMIT CONDITIONS Temperature of room in air conditioning 18℃-35℃ (Cooling) 10℃ -25 ℃ (Heating) SIZE OF APPLIANCE width 463 mm height 775 mm depth 382 mm 775 mm 463 mm 382 mm...
