Client Side Map Descriptors

4.4.1.
Column Title
Map_Descriptor_Name
Data_Array_Name
Data_Array_Offset
Function
4.4.2.
Column Title
Node_Name
Data_Type
Target_DA_Name
Target_DA_Offset
Length
4.4.3.
Column Title
Scan_Interval
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com

FieldServer Related Map Descriptor Parameters

Function
Name of this Map
Descriptor
Name of Data Array
where data is to be
stored in the
FieldServer
Starting location in Data
Array
Function of Client Map
Descriptor

Driver Related Map Descriptor Parameters

Name of Node to fetch
data from
Data type
Data array
FieldServer
Data array
FieldServer
Length of Map Descriptor

Timing Parameters

Rate at which data is polled
Up to 32 alphanumeric
characters
One of the Data Array
names from "Data Array"
section above
0 to maximum specified in
"Data Array" section above
RDBC, WRBC, WRBX
Function
One of the node names
specified in "Client Node
Descriptor" above
Register, Coil, AI, DI
on remote Up to 15 alphanumeric
characters
on remote Up to 15 alphanumeric
characters
1 - 340
Function
Page 8 of 12
Legal Values
Legal Values
Legal Values
≥0.001s
