EXPLICIT DEFINITIONS

WORD
Personal injury, fire hazard or elec-
RWARNING
tric shock may occur.
CAUTION Equipment damage may occur.
If disregarded, inconvenience only.
NOTE No risk of personal injury, fire or
electric shock.

TABLE OF CONTENTS

IMPORTANT ...................................................... i
PRECAUTION ................................................... i
EXPLICIT DEFINITIONS ................................. ii
TABLE OF CONTENTS .................................. ii
SUPPLIED ACCESSORIES ............................ ii
1 PANEL DESCRIPTION ............................ 1-4
I Front panel and remote controller ..................... 1
I Rear panel ....................................................... 3
2 INSTALLATION AND CONNECTIONS 5-10
I Unpacking ........................................................ 5
I Ferrite core installation .................................... 5
I OPC-853 AC cable with line filter .................... 5
I Selecting a location ......................................... 5
I AC power cable connection .............................. 5
I Grounding ........................................................ 6
I Antenna ........................................................... 6

SUPPLIED ACCESSORIES

q w e
DEFINITION
r t y u
i
o
The explicit definitions described at left apply to this in-
struction manual.
I System interconnections .................................. 7
I Separating the remote controller ................... 11
3 OPERATION ......................................... 12-17
I When first applying power (CPU resetting) ... 12
I Setting the ALC levels ................................... 12
I Programming the CI-V address ..................... 13
I Initial settings for CI-V remote control operation
....................................................................... 14
I Operation ....................................................... 16
I Antenna tuner operation ................................ 17
I Protection circuit ............................................ 17
4 MAINTENANCE ......................................... 18
I Troubleshooting ............................................. 18
5 SPECIFICATIONS ..................................... 19
ABOUT CE ................................................ 20
Accessories included with the IC-PW1/EURO: Qty.
q Accessory cable (OPC-104B) .............................. 1
w Coaxial cable (OPC-125B) .................................. 1
e Separation cable (OPC-730) ............................... 1
r Remote control (CI-V) cable (OPC-718) .............. 1
t Remote controller feet ......................................... 2
y Grounding lug ...................................................... 1
u Dummy panel screws .......................................... 2
i Dummy panel ...................................................... 1
o Cable ties ............................................................. 2
ii
