Getting to Know Your Table Saw (continued)
11. Micro-Adjust Rip Fence...
to accurately adjust the rip fence using only one
hand. To move the fence push in on the micro-adjust
knob and rotate.
12. Herc-U-Lift™ Caster Operation
The caster set is activated by pressing down on the metal
platform. This will raise the table saw and allow the saw
to be moved to desired location.
To lower the table saw, press down on the foot pedal.
Make sure the saw firmly rests on the floor. Adjust the
rubber leveling feet if necessary.
13. Storage Hooks
Conveniently holds rip fence and miter gauge when not in
use.
allows the operator
38
Micro Adjust
Miter Gauge
Knob
Rip Fence
