6.4 PL380 parts and assemblies

PL380 Power Amplifier (120V) (QSC part # FG-038000-00)

QSC Part # Description
CH-000579-00 COVER, BOTTOM, , PL3,
LB-000208-00 AGENCY, CERTIFICATION, CLASS A, , FCC
LB-000437-00 LABEL, WARNING, RAIN & MOISTURE, ,
PM-000309-00 INSERT, SHIPPING, , PL380, ,
PM-001401-00 BAG, SHIPPING, POLYPROPYLENE, SERIES 1, 20.5" X 12.5" X 24",
PM-001601-00 CARTON, SHIPPING, , PL380, 23.2" X 21.2" X 5.5",
PM-004001-00 PAD, SHIPPING, , EX/MXA, 21.2" X 23.2",
RD-000001-00 LABEL, SHIPG CRTN , THERMAL
SC-082051-PL PHILLIPS, PANHEAD SERATED BASE, #8, 0.313" L, BLACK, CR111
TD-000235-00 OWNERS MANUAL, PL3 SERIES,
TD-000254-00 MANUAL INSERT, CHINA ROHS, AMPLIFIERS,
TS-000004-WR 3 YEARS WARRANTY
WP-000001-00 ASSEMBLY, CATALOG KIT, , ,
WP-000952-00 SHIP KIT, , PL3, ,
WP-038000-00 CHASSIS ASSY, , PL380, 120V,
WP-038001-00 PCB ASSY, , PL380, 120V,

PL380 Power Amplifier (100V) (QSC part # FG-038000-01)

QSC Part # Description
CH-000579-00 COVER, BOTTOM, , PL3,
LB-000437-00 LABEL, WARNING, RAIN & MOISTURE, ,
PM-000309-00 INSERT, SHIPPING, , PL380, ,
PM-001401-00 BAG, SHIPPING, POLYPROPYLENE, SERIES 1, 20.5" X 12.5" X 24",
PM-001601-00 CARTON, SHIPPING, , PL380, 23.2" X 21.2" X 5.5",
PM-004001-00 PAD, SHIPPING, , EX/MXA, 21.2" X 23.2",
RD-000001-00 LABEL, SHIPG CRTN , THERMAL
SC-082051-PL PHILLIPS, PANHEAD SERATED BASE, #8, 0.313" L, BLACK, CR111
TD-000235-00 OWNERS MANUAL, PL3 SERIES,
TD-000254-00 MANUAL INSERT, CHINA ROHS, AMPLIFIERS,
TS-000004-WR 3 YEARS WARRANTY
WP-000952-00 SHIP KIT, , PL3, ,
WP-038000-01 CHASSIS ASSY, , PL380, 100V,
WP-038001-01 PCB ASSY, , PL380, 100V,

PL380 Power Amplifier (230V) (QSC part # FG-038000-02)

QSC Part # Description
CH-000579-00 COVER, BOTTOM, , PL3,
LB-000437-00 LABEL, WARNING, RAIN & MOISTURE, ,
PM-000309-00 INSERT, SHIPPING, , PL380, ,
PM-001401-00 BAG, SHIPPING, POLYPROPYLENE, SERIES 1, 20.5" X 12.5" X 24",
PM-001601-00 CARTON, SHIPPING, , PL380, 23.2" X 21.2" X 5.5",
PM-004001-00 PAD, SHIPPING, , EX/MXA, 21.2" X 23.2",
RD-000001-00 LABEL, SHIPG CRTN , THERMAL
SC-082051-PL PHILLIPS, PANHEAD SERATED BASE, #8, 0.313" L, BLACK, CR111
TD-000235-00 OWNERS MANUAL, PL3 SERIES,
TD-000254-00 MANUAL INSERT, CHINA ROHS, AMPLIFIERS,
TS-000004-WR 3 YEARS WARRANTY
WC-000356-00 AC CORD ASSY, POWERCONN, 1.5MM2, 3 CONDUCTOR, PL3 SERIES, 100", 250VAC
WP-000952-00 SHIP KIT, , PL3, ,
WP-038000-02 CHASSIS ASSY, , PL380, 230V,
WP-038001-02 PCB ASSY, , PL380, 230V,

Chassis Assembly PL380 (120V) (QSC part # WP-038000-00)

QSC Part # Description
CH-000118-00 RACK EAR, FRONT, , CX902,
CH-000496-00 CHASSIS, MAIN, , PL380,
CH-000582-00 SHIELD, LINE FILTER, , PL380,
CH-000696-00 BRACKET, STOP RING, AC, PL380,
HW-040001-00 BRACKET, ANGLE, #4-40, 0.375" L, ZINC PLATED STEEL,
HW-060090-SO STANDOFF, 0.250" HEX, #6-32, 0.563" L, ALUMINUM, FEMALE
LB-000077-00 WARNING, HIGH ENERGY, , PL 3RU,
124
Qty. Reference
1
1
1
2
1
1
1
0
11
1
1
3
1
1
1
1
Qty. Reference
1
1
2
1
1
1
0
11
1
1
3
1
1
1
Qty. Reference
1
1
2
1
1
1
0
11
1
1
3
1
1
1
1
Qty. Reference
2
1
1
1
2
2
1
Comments
Comments
Comments
Comments
QSC Audio Products, LLC
