PCB Assembly PL325 (120V) continued
QSC Part # Description
RE-122103-30 2.21K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-130102-30 3.01K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-134803-30 3.48K, 1 PCNT, 1/8W, THICK FILM, 1206, 200V
RE-136502-30 3.65K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-145302-30 4.53K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-147502-30 4.75K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-151002-00 5.1K, 5 PCNT, 2W, METAL OXIDE FP, ,
RE-159002-30 5.90K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-175002-30 7.50K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-178701-30 7.87K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-190902-30 9.09K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-210003-30 10.0K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-211303-30 11.3K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-212702-30 12.7K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-215002-30 15.0K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-216501-CM 16.5K, 1 PCNT, 1/2W, METAL FILM, ,
RE-220002-30 20.0K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-224901-30 24.9K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-230002-10 30K, 5 PCNT, 2W, METAL OXIDE FP, MINI,
RE-230102-30 30.1K, 1 PCNT, 1/8W, THICK FILM, 1206, 200V
RE-239202-30 39.2K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-247503-30 47.5K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-269801-30 69.8K, 1 PCNT, 1/8W, THICK FILM, 1206, 200V
RE-310002-30 100K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-310003-30 100K, 1 PCNT, 1/8W, THICK FILM, 1206, 200V
RE-315002-30 150K, 1 PCNT, 1/8W, THICK FILM, 1206, 200V
RE-339201-30 392K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-348702-30 487K, 1 PCNT, 1/8W, THICK FILM, 1206, 200V
RE-375005-BM 750K, 5 PCNT, 1/2W, METAL FILM, ,
RE-410001-30 1.0M, 1 PCNT, 1/8W, THICK FILM, 1206, 200V
SC-063100-PP PHILLIPS, PANHEAD, #6-20, 0.625" L, ZINC, TYPE AB, CR111
SC-081101-SP PHILLIPS, PANHEAD SERATED BASE, #8-18, 0.625" L, BLACK WAXED, TYPE AB, CR111
SW-000104-00 RELAY, SPDT, 24VDC COIL, 20A, 125VAC, T90 STYLE (FOR PLC MODELS)
WC-0.5018-JW JUMPER, TEFLON INSULATION, 18 AWG SOLID, 1 CONDUCTOR, , 0.5" L,
WC-000002-10 JUMPER, BARE, 22 AWG SOLID, 1 CONDUCTOR, , VARIABLE LENGTH, AUTO INSERTABLE
WC-000113-10 JUMPER, 0.8" TEFLON INSULATION, 22 AWG, 1 CONDUCTOR, , 0.9" L, AUTO INSERTABLE
WC-000115-00 WIRE ASSY, AC SWITCH, 16 AWG, 1 CONDUCTOR, PLC, 14" L, BLACK
WC-000115-01 WIRE ASSY, AC SWITCH, 16 AWG, 1 CONDUCTOR, PLC, 7" L, RED
WC-000117-04 WIRE ASSY, SPEAKER, 16 AWG, 1 CONDUCTOR, PL3, 10.50" L, BLACK
WC-000117-05 WIRE ASSY, SPEAKER, 16 AWG, 1 CONDUCTOR, PL3, 9.50" L, WHITE
WC-000117-06 WIRE ASSY, SPEAKER, 16 AWG, 1 CONDUCTOR, PL3, 11.00" L, GREY
WC-000117-07 WIRE ASSY, SPEAKER, 16 AWG, 1 CONDUCTOR, PL3, 9.50" L, BLACK
WC-000118-00 WIRE ASSY, , 16 AWG, 1 CONDUCTOR, PLC, 12.5" L, BLACK
WC-000118-01 WIRE ASSY, , 16 AWG, 1 CONDUCTOR, PLC, 10.5" L, RED
XF-000005-00 BEAD, 100MHZ, 271 OHM,
XF-000023-00 INDUCTOR, COMMON MODE, , 2MH, , ,
XF-000061-00 INDUCTOR, 2 COUPLED WINDINGS, TOROID, 1.9UH, PL/DCA/CX, 230V,
XF-000064-00 TRANSFORMER, HOUSEKEEPING, , , , PLC, ,
XF-000066-00 INDUCTOR, ZOBEL CURRENT SENSE, , 2UH, PLC, ,
XF-000179-00 TRANSFORMER, SWITCHING, 115KHZ, E55, 1500W, DCA1222, 120V/230V,

PCB Assembly PL325 (100V) (QSC part # WP-032501-01)

QSC Part # Description
CA-010002-30 10PF, 5 PCNT, 50V, CERAMIC NPO, 0805,
CA-015002-10 15PF, 10 PCNT, 500V, CERAMIC SL, DISC,
CA-047002-30 47PF, 5 PCNT, 50V, CERAMIC NPO, 0805,
CA-110001-10 100PF, 5 PCNT, 500V, MICA, DIPPED,
CA-110002-30 100PF, 5 PCNT, 50V, CERAMIC NPO, 0805,
CA-133001-10 330PF, 5 PCNT, 500V, MICA, DIPPED,
CA-147003-30 470PF, 5 PCNT, 50V, CERAMIC NPO, 1206,
102
Qty. Reference
16 R47, R72, R75, R84, R170, R195, R198, R207, R240, R264, R265, R267,
R306, R307, R347, R348
4 R79, R202, R290, R293
1 R370
4 R297–R300
2 R11, R137
27 R3, R4, R10, R17, R40, R55, R56, R59, R62–R64, R125, R126, R131, R138,
R163, R178, R179, R182, R185–R187, R282, R287, R327, R330, R362
5 R96, R105, R219, R228, R251
15 R8, R9, R12, R13, R29, R78, R83, R129, R130, R135, R136, R152, R201,
R206, R281
6 R15, R38, R120, R132, R140, R161
1 R360
4 R127, R258, R266, R272
8 R253, R295, R336, R338, R363, R366, R375, R376
1 R122
19 R14, R19, R36, R46, R65, R104, R106, R133, R134, R142, R159, R169, R188,
R227, R241, R245, R259, R329, R337
6 R25, R45, R148, R168, R262, R365
2 R31, R153
10 R18, R141, R229, R242, R244, R271, R291, R294, R331, R346
3 R16, R139, R325
2 R351, R352
4 R49, R50, R172, R173
13 R20, R60, R61, R76, R77, R143, R183, R184, R199, R200, R243, R261, R323
5 R2, R26, R43, R149, R343
4 R283–R286
5 R33, R119, R156, R224, R332
12 R51, R53, R73, R74, R174, R176, R196, R197, R268, R288, R344, R345
12 R52, R54, R57, R58, R175, R177, R180, R181, R333, R335, R341, R342
9 R24, R66, R69, R145, R189, R192, R260, R263, R340
4 R321, R322, R326, R328
2 R339, R371
2 R289, R292
20
8
1 K1
1 W120
2 W1, W2
1 R280
1 W7
1 W6
1 W12
1 W9
1 W11
1 W10
1 W5
1 W8
6 L7–L12
2 L3, L4
1 L6
1 T1
2 L1, L2
1 T2
Qty. Reference
2 C14, C49
2 C16, C50
8 C29, C30, C64, C65, C99, C100, C187, C193
1 C147
8 C5, C6, C9, C18, C40, C41, C43, C53
2 C145, C146
11 C4, C17, C26, C52, C61, C119, C148, C181, C182, C186, C188
Comments
TO SWITCH
TO SWITCH
W12A-B
W9A-B
W11A-B
W10A-B
W5A-B
W8A-B
Comments
