QSC PowerLight3 Series Technical & Service Manual page 116

PCB Assembly PL340 (120V) continued
QSC Part # Description
QD-000014-QD DIODE RECTIFIER ULTRAFAST, 200V, 15A, , MUR1520, TO-220, 35NS
QD-000021-QD DIODE ZENER, 10V, , 1W, 1N4740A, DO-41,
QD-000031-QD MOSFET N-CHANNEL, 60V, 50A, 150W, MTP45N06, TO-220,
QD-000042-00 DIODE RECTIFIER ULTRAFAST, 400V, 3A, , MUR440, DO-201AD, 50NS
QD-000062-10 TRANSISTOR NPN, 40V, 0.2A, 1.5W, 2N3904, TO-92,
QD-000063-10 TRANSISTOR PNP, 40V, 0.2A, 1.5W, 2N3906, TO-92,
QD-000074-00 DIODE RECTIFIER ULTRAFAST, 400V, 15A, , MUR1540, TO-220, 50NS
QD-000076-00 TRANSISTOR NPN, 250V, 8A, 50W, MJE15032, TO-220,
QD-000077-00 TRANSISTOR PNP, 250V, 8A, 50W, MJE15033, TO-220,
QD-000080-20 DIODE ZENER, 11V, , 1W, 1N4741A, DO-41,
QD-000102-30 DIODE, 75V, 0.075A, , IMBD4148, SOT-23, 4NS
QD-000103-30 TRANSISTOR NPN, 40V, 0.2A, 0.2W, MMST3904, SOT-23,
QD-000104-30 TRANSISTOR PNP, 40V, 0.2A, 0.2W, MMST3906, SOT-23,
QD-000105-30 TRANSISTOR NPN, 300V, 0.2A, 0.2W, MMBTA42, SOT-23,
QD-000106-30 TRANSISTOR PNP, 300V, 0.2A, 0.2W, MMBTA92, SOT-23,
QD-000108-30 DIODE, 200V, 0.2A, , BAS21, SOT-23, 50NS
QD-000110-30 DIODE ZENER, 6.2V, , 0.3W, BZX84C6V2, SOT-23,
QD-000113-30 DIODE ZENER, 10V, , 0.3W, BZX84C10, SOT-23,
QD-000115-30 DIODE RECTIFIER ULTRAFAST, 600V, 1A, , MURS160T3, SMB, 75NS
QD-000116-30 DIODE RECTIFIER ULTRAFAST, 200V, 1A, , MURS120, SMB, 35NS
QD-000152-10 DIODE ZENER, 12V, , 1W, 1N4742A, DO-41,
QD-000153-00 DIODE RECTIFIER ULTRAFAST, 400V, 30A, , APT30D40B, TO-247AD, 70NS
QD-000154-00 TRANSISTOR NPN, 230V, 1A, 20W, 2SC4793, TO-220,
QD-000155-00 TRANSISTOR PNP, 230V, 1A, 20W, 2SA1837, TO-220,
QD-000156-00 TRANSISTOR PNP, 100V, 3A, 40W, TIP32C, TO-220,
QD-000170-00 BRIDGE RECTIFIER, , , , 600V 50A, , IN-LINE
QD-000184-00 LED ORANGE, , , , , T-1,
QD-000187-00 LED BLUE, , , , , T-1,
QD-000191-00 LED RED SUPER BRIGHT, , , , , T-1,
QD-000287-10 DIODE ZENER, 3.9V, 5 PCNT, 0.25W, DO-35, ,
QD-000348-00 IGBT, 600V, 75A, 200W, IXGR50N60C2, TO-247,
QD-001943-PN TRANSISTOR PNP, 230V, 15A, 150W, 2SA1943-R, TO-264,
QD-004744-ZA DIODE ZENER, 15V, 5 PCNT, 3W, , ,
QD-005200-NP TRANSISTOR NPN, 230V, 15A, 150W, 2SC5200, TO-264,
QD-005402-DX DIODE, 200V, 3A, , 1N5402, DO-27,
RE-.04703-10 0.47, 5 PCNT, 2W, METAL OXIDE FP, MINI,
RE-.15002-10 1.5, 5 PCNT, 2W, METAL OXIDE FP, MINI,
RE-.56002-10 5.6, 5 PCNT, 2W, METAL OXIDE FP, MINI,
RE-000210-NR NTC, 10 OHMS, 15 AMPS, , , INRUSH LIMIT
RE-000230-NR NTC, 10K, , 15 PCNT, , -4.4 PCNT PER C
RE-001003-30 10, 1 PCNT, 1/8W, THICK FILM, 1206, 200V
RE-001502-10 15, 5 PCNT, 2W, METAL OXIDE FP, MINI,
RE-003921-30 39.2, 1 PCNT, 1/8W, THICK FILM, 1206, 200V
RE-004752-30 47.5, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-005605-EM 56, 5 PCNT, 2W, METAL OXIDE, ,
RE-007502-30 75, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-010002-30 100, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-015007-00 150, 5 PCNT, 2W, METAL OXIDE FP, ,
RE-020002-30 200, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-027401-30 274, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-030003-00 300, 5 PCNT, 2W, METAL OXIDE FP, ,
RE-038301-30 383, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-047002-00 470, 5 PCNT, 2W, METAL OXIDE FP, ,
RE-047502-30 475, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-053602-30 536, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
RE-068002-00 680, 5 PCNT, 2W, METAL OXIDE FP, ,
RE-082002-00 820, 5 PCNT, 2W, METAL OXIDE FP, ,
RE-093101-30 931, 1 PCNT, 1/10W, THICK FILM, 0805, 100V
114
Qty. Reference
4 D21, D22, D46, D47
2 D7, D32
4 Q38, Q41, Q83, Q86
2 D70, D71
2 Q20, Q65
2 Q21, Q66
4 D74, D75, D80, D81
2 Q27, Q72
2 Q26, Q71
2 D95, D96
46 D1–D5, D8–D12, D14, D15, D17, D18, D23–D30, D33–D37, D39, D40, D42, D43,
D48–D52, D55, D59, D63–D65, D67, D69, D89–D91
24 Q5, Q8, Q9, Q13, Q15, Q18, Q25, Q30, Q32, Q49, Q50, Q53, Q54, Q58, Q60,
Q63, Q70, Q75, Q77, Q89, Q92, Q93, Q95, Q90
34 Q1–Q4, Q6, Q10–Q12, Q14, Q23, Q24, Q31, Q33, Q42–Q48, Q51, Q55, Q56,
Q57, Q59, Q68, Q69, Q76, Q78, Q87, Q88, Q94, Q98, Q99
4 Q7, Q16, Q52, Q61
2 Q17, Q62
8 D13, D16, D38, D41, D61, D68, D78, D79
1 D56
1 D66
3 D58, D60, D86
5 D62, D76, D77, D82, D83
1 D57
4 D72, D73, D84, D85
2 Q19, Q64
2 Q22, Q67
1 Q91
1 BR1
3 LD1, LD2, LD7
1 LD11
2 LD5, LD10
2 D6, D31
2 Q96, Q97
8 Q28, Q34, Q36, Q39, Q73, Q79, Q81, Q84
4 D53, D54, D87, D88
8 Q29, Q35, Q37, Q40, Q74, Q80, Q82, Q85
4 D19, D20, D44, D45
32 R88, R89, R91, R92, R94, R95, R97, R99, R102, R103, R107, R108, R111–
R114, R211, R212, R214, R215, R217, R218, R220, R222, R225, R226, R230,
R231, R234–R237
5 R115, R116, R238, R239, R269
7 R80, R98, R203, R221, R354, R355, R373
1 R324
2 R30, R155
4 R353, R356, R358, R359
13 R85, R86, R87, R90, R93, R208–R210, R213, R216, R350, R367, R368
6 R248, R246, R247, R249, R349, R357
12 R5, R6, R100, R110, R123, R124, R223, R233, R308, R309, R312, R313
1 R372
4 R70, R71, R193, R194
10 R21, R27, R144, R150, R334, R364, R381–R384
1 R278
4 R81, R82, R204, R205
4 R67, R68, R190, R191
1 R256
4 R44, R167, R254, R255
2 R279, R280
4 R28, R37, R151, R160
6 R22, R146, R302, R361, R374, R377
2 R274, R275
2 R276, R277
1 R379
Comments
