PCB Assembly PL325 (230V) (QSC part # WP-032501-02)

QSC Part # Description
CA-010002-30 10PF, 5 PCNT, 50V, CERAMIC NPO, 0805,
CA-015002-10 15PF, 10 PCNT, 500V, CERAMIC SL, DISC,
CA-047002-30 47PF, 5 PCNT, 50V, CERAMIC NPO, 0805,
CA-110001-10 100PF, 5 PCNT, 500V, MICA, DIPPED,
CA-110002-30 100PF, 5 PCNT, 50V, CERAMIC NPO, 0805,
CA-133001-10 330PF, 5 PCNT, 500V, MICA, DIPPED,
CA-147003-30 470PF, 5 PCNT, 50V, CERAMIC NPO, 1206,
CA-168003-30 680PF, 5 PCNT, 50V, CERAMIC NPO, 0805,
CA-210005-30 0.001UF, 5 PCNT, 50V, CERAMIC NPO, 1206,
CA-222001-00 0.0022UF, 20 PCNT, 125VAC, CERAMIC Y5U, DISC, YCAP
CA-227001-30 0.0027UF, 10 PCNT, 100V, CERAMIC X7R, 0805,
CA-233001-10 0.0033UF, 10 PCNT, 100V, FILM, DIPPED,
CA-233002-00 0.0033UF, 20 PCNT, 125VAC, CERAMIC, DISC, YCAP
CA-322001-10 0.022UF, 10 PCNT, 100V, FILM, DIPPED,
CA-410001-00 0.1UF, 20 PCNT, 250VAC, FILM, BOX STYLE, XCAP
CA-410002-10 0.1UF, 5 PCNT, 100V, FILM, DIPPED,
CA-410003-10 0.1UF, 10 PCNT, 250V, FILM, DIPPED,
CA-410006-30 0.1UF, 10 PCNT, 50V, CERAMIC X7R, 1206,
CA-410011-00 0.1UF, 10 PCNT, 400V, FILM, DIPPED,
CA-422001-10 0.22UF, 5 PCNT, 50V, FILM, DIPPED, LOW PROFILE
CA-422004-30 0.22UF, 10 PCNT, 50V, CERAMIC X7R, 1206,
CA-447001-00 0.47UF, 20 PCNT, 250VAC, FILM, BOX STYLE, XCAP
CA-447003-00 0.47UF, 10 PCNT, 400V, FILM, WRAPPED, PULSE
CA-510003-10 1.0UF, 20 PCNT, 50V, ELECTROLYTIC, ,
CA-510005-30 1.0UF, 20 PCNT, 50V, ELECTROLYTIC, SMT,
CA-510006-00 1.0UF, 20 PCNT, 250VAC, FILM, BOX STYLE, XCAP
CA-610002-10 10UF, 20 PCNT, 35V, ELECTROLYTIC, ,
CA-610006-30 10UF, 20 PCNT, 16V, ELECTROLYTIC, SMT,
CA-647001-10 47UF, 10 PCNT, 10V, ELECTROLYTIC, , NON-POLAR
CA-647002-10 47UF, 20 PCNT, 50V, ELECTROLYTIC, , LOW PROFILE
CA-710002-10 100UF, 20 PCNT, 25V, ELECTROLYTIC, ,
CA-710004-10 100UF, 20 PCNT, 25V, ELECTROLYTIC, , LOW ESR
CA-747001-10 470UF, 20 PCNT, 16V, ELECTROLYTIC, ,
CA-810003-00 1000UF, 20 PCNT, 90V, ELECTROLYTIC, ,
CA-810004-00 1000UF, 20 PCNT, 55V, ELECTROLYTIC, ,
CA-822200-AE 2200UF, 20 PCNT, 200V, ELECTROLYTIC, ,
CH-000102-00 HEAT SINK, AUDIO, , PLX3002,
CH-000103-00 CLAMP, TO-3PL, 22 GA, PLX3002,
CH-000104-00 HEAT SINK, PS, , PLX3002,
CH-000114-00 CLAMP, DIODE, 2 FINGER, PLX3002,
CO-000009-ZT ZTAB, 0.025" TAB, 1 POS, MALE, AUTO INSERTABLE
CO-000036-CO JACK, SPEAKON, 4 POS, FEMALE,
CO-000155-00 HEADER, 0.1" CENTERS, 2 POS (1X2), MALE, RAMP LOCK
CO-000193-00 HEADER, 0.1" CENTERS, 20 POS (2X10), MALE, BOX
CO-000194-00 HEADER, 0.1" CENTERS, 20 POS (2X10), MALE, LATCHING BOX
CO-000196-00 HEADER, 0.1" CENTERS, 3 POS (1X3), MALE, RAMP LOCK
HW-000001-FC FUSE CLIP, PC MOUNT, , , TIN PLATED BRASS, 3AG
IC-000024-00 CONTROLLER, PWM, SG3525AN, ,
IC-000046-30 OPAMP, DUAL, TLO72, SMT,
IC-000047-30 COMPARATOR, DUAL, LM393, SMT,
IC-000048-30 OPAMP, DUAL, MC33078, ,
IC-000051-00 OPTO ISOLATOR, , MOC8101, ,
IC-000053-30 TIMER, DUAL, LM556, ,
IC-000054-30 COMPARATOR, QUAD, LM339AM, SMT,
IC-000073-30 TRANSCONDUCTANCE OPAMP, DUAL, LM13600M, ,
IC-000133-30 COMPARATOR, SINGLE, LM311, SMT,
IC-000134-00 DRIVER, MOSFET, IR2110, ,
IC-000135-00 TOP SWITCH, , TOP210, ,
IC-005532-OP OPAMP, DUAL, NE5532, ,
MS-000048-HS HEAT SINK, TO-220, 1.375" X 0.86" X 0.395", LONG TAB, PLUG-IN
MS-000115-30 FUSE, 1.0A, 24V, 1206, SLO
MS-150250-FU FUSE, 15A, 250V, 0.25" X 1.25", FAST
106
Qty. Reference
2 C14, C49
2 C16, C50
8 C29, C30, C64, C65, C99, C100, C187, C193
1 C147
8 C5, C6, C9, C18, C40, C41, C43, C53
2 C145, C146
11 C4, C17, C26, C52, C61, C119, C148, C181, C182, C186, C188
2 C25, C60
9 C75, C81, C85, C93, C94, C95, C96, C120, C124
2 C122, C127
11 C20, C23, C24, C55, C58, C59, C68, C98, C108, C109, C128
1 C113
2 C115, C118
2 C27, C62
1 C126
4 C8, C12, C44, C47
13 C28, C34, C35, C63, C69, C70, C84, C87, C90, C129, C134, C156, C157
19 C19, C54, C88, C116, C125, C135, C155, C162, C163, C177–C180, C183,
C185, C189–C191, C194
2 C107, C123
2 C10, C45
2 C121, C39
1 C117
1 C144
1 C80
2 C13, C48
2 C110, C112
7 C3, C31, C38, C66, C86, C114, C192
1 C184
11 C7, C11, C42, C46, C71, C91, C92, C102, C104–C106
5 C21, C22, C56, C57, C89
11 C15, C32, C33, C51, C67, C72, C78, C79, C139, C142, C143
3 C138, C149, C150
7 C73, C74, C76, C77, C82, C83, C131
10 C152, C153, C159, C160, C165, C166, C169, C170, C173, C174
10 C151, C154, C158, C161, C164, C167, C168, C171, C172, C175
6 C132, C133, C136, C137, C140, C141
4
9
2
4
3 J19, J20, J21
2 J7, J8
1 J13
1 J5A
3 J14A, J3B, J5B
1 J11
2
1 U19
2 U11, U12
1 U10
2 U1, U6
2 U15, U17
1 U14
1 U13
1 U3
4 U4, U5, U8, U9
1 U18
1 U16
2 U2, U7
1
1 R314
1 F1
Comments
REF: F1
REF: Q91
