Summary of Contents for Grandstream Networks GXE5024 IPPBX
- Page 1 Grandstream GXE502x IPPBX Quick Start Guide...
- Page 2 Ready access to power and UPS or surge protector DHCP: dynamic host configuration protocol – automatically • DHCP must be configured with DHCP Option 66 enabled for Grandstream assigns IP addresses phones to be auto-provisioned (Grandstream default configuration. Non- Extension Length: number of characters in an extension. For Grandstream IP phones will need to be configured manually).
- Page 3 GXE Configuration Steps ONE. Access the web GUI (web configuration pages): 1. Connect a Windows PC to the same switch/hub that is connected to the GXE. 2. Click on the start menu and go to the “Run” option and type “cmd” to launch the Windows command prompt window.
- Page 4 Note: if you don’t want to use the Auto Provisioning, you can simply Click on the button labeled: “Finish”. To ensure proper auto-provisioning of Grandstream IP phones, connect the IP phones to the switch/hub after Step 3, as the GXE will only auto-provision phones found during this stage.
- Page 5 IP address of the phone in your web browser. 3. Type in “admin” for the password on the phone’s login screen (example given for Grandstream phones). 4. When you are logged in, the advanced settings page will load automatically.
- Page 6 FOUR: Configuring the Network Settings 1. Click on “System Configuration” in the left hand column. This will automatically load the Network Settings configuration page (See Figure 4-1). On this page you can configure the LAN and WAN settings such toggling between using DHCP or using a static IP address.
- Page 7 FIVE: Configuring the System Settings 1. Click on “System Configuration” in the menu bar on the left. 2. Click on “System Settings” in the expanded menu to load the system settings page (See Figure 5-1). This page lets you configure the login and contact information of the system administrator, email options, time zones, call record servers and storage quotas.
- Page 8 SIX: Configuring PSTN Lines (if available) 1. Click on TRUNK/Phone Lines on the left menu bar to load the Internal PSTN Trunk Line configuration page (See Figure 6-1). 2. Click on the button “Add” to add a new line call control (Figure 6-2). 3.
- Page 9 SEVEN: Configuring SIP Trunks (if available) 1. Click on TRUNK/Phone Lines on the left menu bar and then click on “SIP Trunk” to load the SIP Trunk configuration page (Figure 7-1). 2. Your SIP service provider will provide you with SIP account and registration information, which you may enter in the respective fields of this page.
- Page 10 NINE: Configuring the Call Routing Profile 1. Click on “Call routing” in the left hand column. This will automatically load the Call routing Profile Page (See Figure 9-1). On this page you can configure the call routing for internal, inbound and outbound calls. 2.
