Upgrading The Computer
Figure 6 - 7
6
Primary HDD
Assembly Insertion
6 - 10 Upgrading the Hard Disk Drive(s)
Inserting the Hard Disk Into the Primary HDD Bay
1. Make sure the HDD assembly is aligned with the black taped area
2. When aligned, carefully insert the HDD assembly
connectors line up.
3. Replace the hard disk bay covers and screws.
2
1 1
2
.
1
into the case so that the
