Euphonix R-1 Transfer Station Operation Manual

AES Title Import

To Import an AES 31 Title into the R-1:
1. Left-click on the Track name in the Navigation Bar and select Import AES 31.
The Import dialog appears.
2. Configure the Import options:
3. Click the Browse button to navigate to and select the .adl file to Import.
4. Click Import.
The AES file is imported with its audio to the R-1 format.
Audio in a Windows folder not associated with the adl file you are importing will not
be imported to the R-1. When importing adl files to an R-1, the system will only import
audio that is expected to be associated with the adl title. To import audio to the R-1 that
is not associated with an adl or R-1 title, see section 3.2 on page 26 in the R-1 3.0 Ad-
dendum.

AES Title Import as Sheet

Left-click on the Sheet in the Navigation Bar and select Import AES Title. Follow the
same instructions as Import AES Title but a new Sheet is created within the current
Title instead of a new Title.
This feature could be used to put all takes of a particular song into the same R-1 Title,
or merge all songs of an album into the same Title.
Import Audio Files (Allows or disallows import of associated audio. If the
audio does not exist on the target drives where you are importing your title,
select this option.)
Overwrite existing audio file content (overwrites audio with same Global
Unique ID (GUID) on Transfer Station disks)
Import new audio files to library
Use same name as R-1 Title (puts audio that does not exist on R-1 disks into
same library as Title file)
Use another name (create a separate folder to store the audio)
Import R-1 Title (copies the R-1 Title previously exported with the AES
files back onto the R-1)
Set export path (sets default import folder)
Browse (specify a folder other than default import folder)
