Export to AES 31

To export a Sheet as an AES 31 EDL:
1. Right-click on the Track name in the Navigation Bar and select Export to
AES 31.
The Export dialog appears.
2. Select the desired Export options:
3. Click Export.
Tips for Export Operation
When exporting titles with multiple sheets, all audio associated with the entire title can
be exported with the first Sheet. This allows the R-1 to be left unattended while you do
other tasks. When exporting the first title, select the Export all audio files in Title's
library option.
When all audio has exported, export all other sheets belonging to that title. It is a good
idea to leave the Export all audio files in Title's library option selected when export-
ing the other sheets, just in case material from one of the other sheets belongs to a dif-
ferent library. You should also make sure that each sheet is exported to the same
Windows folder to avoid duplicate copies of the material. In this case, do not select the
Overwrite existing audio files so each time you export a sheet belonging to the same
Library, you would not export audio previously exported.
Export Title file only (when selected, the next two options are inactive)
Export R-1 Title (Puts a version of the R-1 title file with the ADL file and
Audio files for later use on an R-1)
Overwrite existing audio files
Export all audio files in Title's library
Export all tracks (toggles with next option)
Export selected tracks (toggles with previous option)
Set export path (sets default export folder)
Browse (specify a folder other than default export folder)
File name (change exported file name)
6
