AUDIO | VIDEO MEDIA CONTROLLER
4.5.2

Knob Functions

Each knob has the following controls:
• Touching the knob's image on the Touchscreen toggles the state of its pri-
mary parameter, such as EQ Band 1 on/off. When on, a small green LED
lights on the lower left.
• Pressing the Shift key and touching the knob's image on the Touchscreen
toggles its secondary parameter (if it exists). This is used to toggle an aux
send between pre/post fader.
This can also change the knob function between two or more parameters,
such as EQ Frequency and Q.
When active, a small yellow LED lights on the upper left.
4.5.3

Knob Set Navigation Keys

Since a knob set may have more parameters than knobs, the PAGE
PAGE
keys scroll among them.
PAGE
Press the PAGE
pressing PAGE
a previous page to go to.
PAGE
Press the PAGE
the PAGE
page to go to.
CFG
PAGE
Figure 4-5 Knob Set navigation keys
key to scroll to the previous page. When on the first page,
key does nothing. The PAGE
key to scroll to the next page. When on the last page, pressing
key does nothing. The PAGE
CFG
PAGE
key lights yellow when there is
key lights yellow when there is a next
and
35
