Physically Linking Artist Media Controllers; Foldout Leg (Left); Riser Bracket (Right); Removing Side Panels (Left); Removing Riser Brackets - Euphonix MC control User Manual

Two larger, detached riser brackets elevate and angle the unit more than the
foldout legs. Use moderate force to snap them into the bottom panel as shown
in Figure 2-1.
To remove the riser brackets:
1. Slide the side panels off (Figure 2-2 left).
16
2. Press the tabs to release the riser brackets (Figure 2-2 right).
3. Lift the riser bracket out of the MC Control to remove
2.1.2

Physically Linking Artist Media Controllers

An MC Control can be physically attached to up to four MC Mixes and one MC
Transport to form a larger, stable control surface. See Surfaces on page 48 to use
EuControl to link the surfaces in the desired order.
Foldout
leg
Riser
bracket
Figure 2-1 Foldout leg (left); riser bracket (right)
Figure 2-2 Removing side panels (left); removing riser brackets
