HG755420UM
EN GAS HOB
USER MANUAL
GB

Advertisement

loading

  Related Manuals for Electrolux HG755420UM

  Summary of Contents for Electrolux HG755420UM

  • Page 1 HG755420UM EN GAS HOB USER MANUAL...
  • Page 2 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.
  • Page 3: Table Of Contents

    Contents CONTENTS 4 Safety information 6 Installation 12 Product description 13 Operation 15 Helpful hints and tips 16 Care and cleaning 17 What to do if… 18 Technical data 19 Environment concerns The following symbols are used in this user manual: Important information concerning your personal safety and information on how to...
  • Page 4: Safety Information

    Safety information SAFETY INFORMATION WARNING! These instructions are only valid in the countries whose symbols appear on this booklet's cover. For your safety and correct operation of the appliance, read this manual carefully before installation and use. Always keep these instructions with the appliance even if you move or sell it.
  • Page 5 Safety information • Pots must not enter the control zone. • Do not use not stable cookware to prevent from tilt and accident. • Do not put flammable products or items that are wet with flammable products, and/or fusible objects (made of plastic or aluminium) and/or fabrics in, near or on the appliance. There is the risk of explosion or fire.
  • Page 6: Installation

    Installation • This appliance is not connected to a combustion products evacuation device. It must be installed and connected in accordance with current installation regulations. Particular attention must be given to the relevant requirements regarding ventilation. • The use of a gas cooking appliance cause heat and moisture in the room in which it is installed.
  • Page 7: Important Safety Requirements

    Installation Important safety requirements This hob must be installed in accordance with the Gas Safety (Installation and Use) Regula- tions (Current Edition) and the IEE Wiring Regulations (Current Edition). For appliances installed in the Republic of Ireland please refer to NSAI- Domestic Gas Instal- lation I.S.
  • Page 8: Injectors Replacement

    Installation End of shaft with nut Washer Elbow Connection to the gas supply should be with either rigid or semi-rigid pipe, i.e. steel or cop- per. The connection should be suitable for connecting to R 1/2 (1/2 BSP male thread). When the final connection has been made, it is essential that a thorough leak test is carried out on the hob and installation.
  • Page 9: Electrical Connection

    Installation Adjustment of minimum level To adjust the minimum level of the burners: Light the burner. Turn the knob on the minimum position. Remove the knob. With a thin screwdriver, adjust the by-pass screw position. The by-pass screw – If you change from natural gas 20 mbar to liquid gas, fully tighten the by-pass screw in.
  • Page 10 Installation fied electrician, e.g. your local Electricity Board, or a contractor who is on the roll of the National Inspection Council for Electrical Installation Contracting (NICEIC). The manufacturer declines any liability should these safety measures not be observed. This hob is designed to be connected to a 230 V 50 Hz AC electrical supply. Before switching on, make sure the electricity supply voltage is the same as that indicated on the hob rating plate.
  • Page 11: Possibilities For Insertion

    Installation The replacement of electric cable must be carried out exclusively by the service force centre or by personnel with similar competencies, in accordance with the current regulations. Replacement of the connection cable To replace the connection cable use only H05V2V2-F T90 or equivalent type. Make sure that the cable section is applicable to the voltage and the working temperature.
  • Page 12: Product Description

    50 cm 2 120 cm 2 180 cm 2 360 cm 2 MANUFACTURER: ELECTROLUX ITALIA S.p.A. C.so Lino Zanussi, 30 33080 PORCIA (PN) - ITALIA PRODUCT DESCRIPTION Cooking surface layout Hob top Semi-rapid burner...
  • Page 13: Operation

    Operation OPERATION Ignition of the burner WARNING! Be very careful when you use open fire in kitchen environment. Manufacturer decline any responsibility in case misuse of the flame Always light the burner before you put cookware. To light the burner: Turn the control knob counterclockwise to the maximum position ( ) and push it down.
  • Page 14: Turning The Burner Off

    Operation Burner cap Burner crown Ignition candle Thermocouple WARNING! Do not keep the control knob pushed for more than 15 seconds. If the burner does not light after 15 seconds, release the control knob, turn it into off posi- tion and try to light the burner again after minimum 1 minute. In the absence of electricity you can ignite the burner without electrical device;...
  • Page 15: Helpful Hints And Tips

    Helpful hints and tips When you install the grate of the Triple Crown burner afterwards, align the hollow part of the grate with the reference on the plate attached to the glass. CAUTION! Be very careful when you put the pan supports back on their position. There is a risk of scratching the glass hob top.
  • Page 16: Care And Cleaning

    Care and cleaning Information on acrylamides Important! According to the newest scientific knowledge, if you brown food (specially the one which contains starch), acrylamides can pose a health risk. Thus, we recommend that you cook at the lowest temperatures and do not brown food too much. CARE AND CLEANING WARNING! Switch the appliance off and let it cool down before you clean it.
  • Page 17: What To Do If

    What to do if… At the end rub the appliance dry with a clean cloth. In order to avoid damaging the hob top pay attention when replacing the pan support. Cleaning of the spark plug This feature is obtained through a ceramic ignition candle with a metal electrode. Keep these components well clean to prevent difficult lighting and check that the burner crown holes are not obstructed.
  • Page 18: Technical Data

    Technical data MOD. MOD. MOD. TYPE PROD.NO. 230V-50Hz PROD.NO. PROD.NO. 0049 SER.NO. IP20 SER.NO SER.NO 03 IT DATA DATA MADE IN ITALY MODEL MODEL Stick it on Guarantee Card and send this part Stick it on Guarantee Card and keep this part Stick it on instruction booklet These data are necessary to help you quickly and correctly.
  • Page 19: Environment Concerns

    Environment concerns Electric supply: 230 V ~ 50 Hz 3 core flexible cable with non rewireable plug fitted with a 3 amp cartridge fuse Category: II2H3+ Gas connection: R 1/2" Gas supply: G20 (2H) 20 mbar Appliance class: By-pass diameters Burner Ø...
  • Page 20: Packaging Material

    Packaging material The packaging materials are friendly to the environment and can be recycled. The plastic components are identified by marking: >PE<,>PS<, etc. Discard the packaging materials as household waste at the waste disposal facilities in your municipality.
  • Page 24 www.aeg.com/shop 397197101-B-072011...
