4.3.1 Verify NEXRAD

To select the Weather Page from the Data Link Page:
1. Turn the large outer knob on the right and move through the Page Groups until the NAV Page
Group is selected.
2. Turn the small inner knob on the right until the Weather Page is selected.
displayed on the screen similar to
NEXRAD timer in the upper right corner to confirm delivery of NEXRAD.

4.3.2 Verify Graphical METAR

To display Graphical METARs on the NAV Weather Page:
1. Select the NAV Weather Page.
2. Press CRSR. The upper left hand corner field flashes.
3. Turn small right knob and select 'METAR'.
Graphical METAR data is displayed on the screen similar to
Press CRSR.
4.
available
.
190-00355-04
Rev. K
, if available
Figure 4-3

Figure 4-3. Weather Page

Figure 4-4. Graphical METAR Page

GDL 69/69A XM Satellite Radio Activation Procedures
NEXRAD data is
If no weather is in the area, look for
.
Figure 4-4
, if
Page 15
