ENSTROM 480B OPERATOR'S MANUAL
GARMIN GDL 69AH XM WX SATELLITE
HELICOPTER SERIAL NO.
HELICOPTER REGISTRATION NO.
THIS SUPPLEMENT MUST BE CARRIED IN THE
HELICOPTER AT ALL TIMES IF EQUIPPED WITH THE
GARMIN GDL 69AH. CHAPTERS 1, 2, 3, AND 4 ARE
FAA APPROVED.
FAA APPROVED BY:
FAA APPROVAL DATE:__________________________________
This electronic document is not linked to a subscription for revision control or distribution. Refer to the Optional Equipment
Supplement Publications Status link under the Technical Support Page of the Enstrom Helicopter website for the current revision
FAA APPROVED
ROTORCRAFT FLIGHT MANUAL
SUPPLEMENT
WEATHER/RADIO RECEIVER
REPORT NO. 28-AC-062
STEVEN L. LARDINOIS, ACTING MANAGER
CHICAGO AIRCRAFT CERTIFICATION OFFICE
CENTRAL REGION
FEDERAL AVIATION ADMINISTRATION
THE ENSTROM HELICOPTER CORPORATION
2209 22
MENOMINEE, MICHIGAN 49858-0490
level of this Rotorcraft Flight Manual Supplement.
AND
* * * * *
* * * * *
STREET
ND
Jun 5/14
