Contact closure ............................ 1 female 9-pin D connector (shared with serial control port)
Contact closure pin configuration... pin 1 = input 1, pin 4 = input 2, pin 5 = ground, pin 6 = input 3,
IR control port .............................. 1 3.5 mm captive screw connector, 5 pole (shared with the MLC/IR serial control
Program control ........................... Extron's control program for Windows®

General

Power ............................................. 100VAC to 240VAC, 50/60 Hz, internal, autoswitchable
MLS 306, MLS 506 ........... 20 watts
MLS 506MA ...................... 60 watts
MLS 506SA ....................... 100 watts
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) / 10% to 90%, non-condensing
Rack mount ................................... Yes, with included brackets
Enclosure type .............................. Metal

Enclosure dimensions

MLS 306 ............................. 1.75" H x 17.5" W x 9.4" D (1U high, full rack width)
MLS 506 Series ................. 3.5" H x 17.5" W x 9.4" D (2U high, full rack width)

Product weight

MLS 306 ............................. 5.5 lbs (2.5 kg)
MLS 506 ............................. 7.0 lbs (3.2 kg)
MLS 506MA ...................... 10.2 lbs (4.6 kg)
MLS 506SA ....................... 8.6 lbs (3.9 kg)

Shipping weight

MLS 306 ............................. 9 lbs (4.1 kg)
MLS 506 ............................. 14 lbs (6.4 kg)
MLS 506MA ...................... 17 lbs (7.7 kg)
MLS 506 SA ...................... 16 lbs (7.3 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
pin 7 = input 4, pin 8 = input 5, pin 9 = input 6
port) for 38 kHz IR signals
Extron's Simple Instruction Set™ – SIS™
Operating +32° to +122°F (0° to +50°C) / 10% to 90%, non-condensing
4.4 cm H x 44.4 cm W x 23.9 cm D
(Depth excludes connectors and knobs. Width excludes rack ears.)
8.9 cm H x 44.4 cm W x 23.9 cm D
(Depth excludes connectors and knobs. Width excludes rack ears.)
MLS 306, MLS 506, MLS 506MA, MLS 506SA • Specifications
(7.32-04302-D5)
1-5
