10 and 12 seer single package heat pump
Hide thumbs

Advertisement

Table of Contents

10 and 12 SEER
Single Package Heat Pump
Single
Package
Heat Pump
IMPORTANT:
Read this owner information to become familiar with the capabilities and use of your
appliance.
Keep this with literature on other appliances where you have easy access to it
in the future. If a problem occurs, check the instructions and follow recommendations given.
If these suggestions
don't eliminate
your problem, call your installing contractor
or
distributor in your area.
INTRODUCTION
Your heat pump is a unique, all weather comfort-
control system appliance. The basic operation
of the heating/cooling system is described and
illustrated on page 1 of this manual.
The
surprising fact that heat exists in air even at
below-freezing temperatures is actually the basic
law of physics which the heat pump uses to
provide energy saving heating comfort.
At
outdoor temperatures of 47 ° Fahrenheit or (or
8 ° Celsius),
your
heat pump
can deliver
approximately 2 to 3 units of heat energy per
each unit of electrical energy used, as com pared
to a maximum of only 1 unit of heat energy
produced with conventional
heating systems.
During the cooling
season, the heat pump
reverses
the flow
of the heat-absorbing
refrigerant to become an energy-efficient, central
air conditioner.
