Interface Cables
For RGB 202 Rxi and Other Universal Interfaces with 9-pin D Inputs
90° LBC - Laptop Breakout
Cables with Audio
LBC - Laptop Breakout Cables with 90° Connector for
9-Pin Interfaces
desCription
Extron 90° LBC - Laptop Breakout Cables with Audio directly connect video and audio from
a laptop, notebook, or any computer without a local monitor to any 9-pin Extron interface, such
as the RGB 202 Rxi. For small spaces and high traffic areas, the 90° connector angle enables
low profile, clean-looking cable connections in upward or downward directions. The LBCs with
audio include 3.5 mm stereo mini plugs.
LBC 90 VGA HR A
VGA Cable: 9-pin D 90° Female to 15-pin HD Male LBC with Audio
model
LBC 90 VGA HR A/3
LBC 90 VGA HR A/6
LBC 90 VGA HR A/12
LBC 90U VGA HR A
VGA Cable: 9-pin D 90° Up Female to 15-pin HD Male LBC with Audio
model
LBC 90U VGA HR A/3
LBC 90U VGA HR A/6
LBC 90U VGA HR A/12
LBC 90 Mac HR A
Mac 15-pin D Cable: 9-pin D 90° Female to 15-pin D Male LBC
with Audio
model
LBC 90 Mac HR A/3
LBC 90 Mac HR A/6
LBC 90 Mac HR A/12
68
(continued)
Version desCription
3'
(90 cm)
.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6'
(1.8 m)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12'
(3.6 m)
.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Version desCription
3'
(90 cm)
.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6'
(1.8 m)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12'
(3.6 m)
.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Version desCription
3'
(90 cm)
.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6'
(1.8 m)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12'
(3.6 m)
.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
