SAFETY INSTRUCTIONS Read before operating equipment This product was designed and manufactured to meet strict quality 12, Cleaning -The applianceshould be cleaned only as recommended by the manufacturer. and safety standards.There are, however, some installationand operation precautions which you should be particularly aware of. 13.
Page 4
an electrical shock For the safety of everyone in your household, please do The lightning flash within a triangle tells you that the voltage inside may cause not remove product covering. The exclamation point within the triangle calls attention to features for which you should read the enclosed literature closely to prevent operating and maintenance problems.
Contents C Installation Your remote control 2 Preparation 3 Installation 5 StoreTV channeJs 5 Select the menu languageand channel system 5 Automatic installation 6 Manual installation 6 Enter or modify a channel name 7 Select favorite'lV channels 7 InstallTV setup 8 The keys on the front of the receiver box 8 C Operation Use of the remote control 9-10...
Preparation _Your remote control EXTERNAL p.26 selection of A/V1, A/V2, A/V3. A/V4 (FRONT).A/V5. A/V6 or VGA Mode buttons p. 9 POWER turn on/off p. 9 ' TV, CBL VCR, AMP, HD, SAT. DVD or CD selection closed caption on/off p. 18 I-II mono-stereo-SAP selection...
Preparation Do not insert the power plug in a wall socket before all connections are made. Place the receiver box wherever you want, but leave at least 2" space free all around the box for ventilation and do not cover the ventilation openings (e.g. on the ground, in a cupboard, behind a wall, in another room..) To prevent any unsafe situations, do not place any objects on top of the monitor or the receiver.
Page 8
With the simplified remote control supplied with the monitor you can: switch menu on or off with the MENU key select a menu or menu item with the cursor keys activate the sebection you made with the OK key switch your flat color television to standby or on again with the 0 mute the sound with the _i_ key select predefined picture and sound settings with the SMART CONTROLS PICTURE and SOUND keys...
Installation ,Select the INSTALLATION menu" Pressthe menu _] key to display/cancel the MAIN MENU. Use the cursor keysup/down to select the menu item INSTALLATION. oooo Note:TheINSTALLATION menu _snot availableif a n_tJng hasbeen blockedvia the Lockmenus.(Seep__4d5.) _menu C To use the menus select adjustments Use the cursor in the up/down, left/right directions to select a menu item.
CAutomatic installation All possible broadcasted'IV channels have been programmed at the factory. Select Automatic Installation in the INSTALLATION menu. Select On with the cursor keys left/right to activate. All TV channels you can receive are put in a favorite list. Wait until the Searching bar at the bottom of the screen has disappeared and the message Ready is displayed.
Enter or modify a channel name You can assigna name to theTV' channel. A name with up to five letters or numbers can be given to each TV channel, For example CNN, SUPR..You can also name any peripherals (except the computer) that are connected. Select Channel Label in the INSTALLATION menu with the cursor up/down and press the OK key.
_ Install Setup The Setup menu allows you to adjust initial settings, i,e. those which are not related to the installation of theTV channels. The Setup menu contains items that control the settings of the'l-V's functions, features, services and peripherals you may have connected, Select Setup in the INSTALLATION menu and press the OK key.
Page 13
Operation Use of the remote control EXTERNAL Selecting your external POWER sources Press to turn on!off the _ Press this key repeatedly to select The TV is never completely powered off unless it A/V|, A/V2, A/V3 CVBS, As'V3RGB, ..is physically unplugged. '\..................
Dual Screen on/off i ..SOUND menu p. 12 See Dual Screen, p. 19 FEATURE menu p, 13 "\ ....PICTURE menu p. 11 ....1_3 Display Format Press this key to summon a list of available ................•.h displayformats for video images. Freeze Press this key repeatedly to select another When pressed,the displayed picture is frozen,...
Sound menu Select the menu item with the cursor up/down and adjust the settings with the cursor left/right. Store the modified adjustments forVolume, Balance,Treble and Bass values and incredible Surround, as well as theVolume and Balance in the Headphone menu for all channels with Save Sound PP in the FEATURES menu. Sound mode Select Stereo or Mona if the'IV channel transmits stereo sound.
Features menu Select the menu item with the cursor up/down and adjust the settings with the cursor lefo'right. Sleeptimer With the sleeptimer you can set a time period after which the"IV should switch itself to standby. The counter can be set from Offup to t80 rnin.
Page 18
TV Ratings Select TV Ratings in the LOCK menu with the cursor down. Press the OK key to activate. A list appears, showing the age-basedTV ratings. Block or unblock an item in the age-based list with the cursor left/right, When an item on the age-based list is blocked, all items below that item of the same group are blocked as well.
Page 19
Movie Ratings This function allows you to control access to individual movies based on their MPAA ratings (Motion Picture Association of America) Select Movie Ratings in the LOCK menu with the cursor down. Press the OK key to activate, A list appears, showing all valid MPAA content ratings. Select a movie rating with the cursor up/down.
Page 20
Change Access Code This function allows you to create or change a Personal identification Number or access code in the menu. Select Change Code in the LOCK menu with the cursor down. Press the OK key to enter the menu. Enter a new codenumber with the digit keys, All number combinations from 0000 to 9999 are valid numbers (except 0711),...
Page 21
Message With this function you can enter a personal message on 2 lines which will be displayed automatically when the set is turned on. For example: I'll be late this evening. Don't wait for dinner. Change Press the OK key to start entering the message. Select with the cursor up/down the Setter or number you want to enter.
(Closed Caption Closed Captioning allows you to read the dialog of television programs on theTV screen. Designed to help the hearing impaired, this feature uses on screen "text boxes" to show dialogue and conversations while the TV program is in progress. Captions will appear on the screen only during captioned broadcasts.
Dual screen Press the _]_ key to turn on or off Dual Screen. ThelV screen will be divided in 2 different pictures. The picture on the left side is the selected "IV channel or AN source. The picture on the right side is the picture from the'IV channel in the favorite program list following or preceding the selected "IV channel or A/V SOUrCe,...
Page 24
Connect Peripheral Equipment There is a wide range of audio and video equipment that can be connected to your receiver.The following connection diagrams show you how to connect them to the back or the front side of the receiver. (,Video recorder Note: Do not ploce ,lout video recorder too close to the screen as some video recorders may be susceptible for signals ou[ of the displcsF...
(,VCR with other peripherals (except Photo CABLE' Iq I ..Do-o I o ..®-0-o I j 0-2o_ ®- 0-0- OL,o O--,--@-O-O-O-, J IN ... ® ® ANTEN_ Interconnect yourVCR with an extra RF cable (_). To obtain better picture quality, also connect the Video, Audio left and Audio right (only for stereo equipment) cables to the VIDEO, AUDIO L and AUDIO R inputs of the A/V IN t or AN IN 2 sockets.
Page 26
Photo Connect the cable of your Photo CD to AN IN 3. Photo CO Select INSTALLATION in the Main Menu. Select Photo CD in the Setup menu. Select Photo CDYes to obtain better picture quality for your Photo CD. Note:This has only effect when connected to the RGB input of AV3. Press the MENU [_] key repeatedly to switch off all menus.
( DVD player Connect the three separate component video cables to the DVD player's Y, Cb and Cr jacks and to the Y, Cb and Cr A/V6 IN jacks on the receiver. Connect the audio cable to the DVD player's AUDIO L and R jacks and to the L and RAUDIOA/V6 jacks on the receiver.
_'-, Connect your computer Connect one end of the supplied VGA cable to the video card of the computer and the other end to the VGA MONITOR IN @) connector at the rear side of the receiver box. Fix the connectors firmly with the screws on the plug. In case of a Multimedia computer, connect audio cables to the audio outputs ..k..) <j of your Multimedia computer and to the AUDIO MONITOR IN R (right) and...
Page 29
Daisy chaining The Active Loop Through facility makes it possible to make a daisy chain. Connect the monitors (max. 2) before inserting the mains plugs in the wall sockets. Connect anotherVGA cableto the VGAOUT connector (D at the back of the monitor and to theVGA IN connector of a second VGA monitor.
select connected equipment EXTERNAL Equipment connected to the rear or to the front side of the receiver Press the EXTERNAL key repeatedly to select A/Vt, A/V2,A/V3,A/V3 RGB, AVI4,A/VS,A/V6 or VGA, according to where you connected your equipment at the rear or the front side of your receiver. ®...
(VCR Control keys Most of the audio and video equipment from our range of products can be operated with the remote control of your TV. Press the TV, CBL, VCR, AMP, HD, SAT,DVD or CD key according to the equipment you want to operate with this remote control. See Use of the remote control, p.
BlockingOptions menu (See p.15) is set to OFF. Press the menu (_] key. Select FEATURES. Select Lock Access, Enter your access code.The LOCK menu appears. Select Blocking Options. Select Master Disable and switch to ON,All selected ratings will be disabled, Telephone number Philips Customer Care Centre If your problem is not solved...
Rules.These limits are designed to provide reasonable protection againstharmful interference in a residential installation.This by Philips Consumer Electronics may void the user's authority to equipment generates, uses, and can radiate radio frequency energy operate the equipment-...
Conversion Table A: channel to frequency (in MHz) for off-air channels. The frequencies used by a cable company may differ from the frequencies on the table. Consult your cable company or your dealer for detailed information. Channel Channel :: Channel Channel 55.25 471.25...
C Glossary Aspect Ratio Multichannel Television sound (MTS) S-Video Input The broadcast standard that allows for The proportions of a rectangular display Allows direct connection of high- stereo sound to be transmitted with the screen. NTSC television has a 4:3 ratio; resolution video sources, such as a Super HDTV is 16:9.
