Specifications - Extron electronics Basic MediaLink Controllers MLC 52 IR Brochure & Specs

specifications

Specifications
Control/remote — mlC Controller host ports
Serial control port ........................................... 1 front panel 2.5 mm mini stereo jack
Baud rate and protocol ..................................... 9600 baud, 8 data bits, 1 stop bit, no parity
Serial control pin configurations ........................ Mini stereo jack: tip = TX, ring = RX,
Program control ............................................... Extron's configuration program for Windows
Control — projeCtor/plasma (mlC 52 rs)
Projector control port ....................................... (1) 3.5 mm direct insertion captive screw
IR control ........................................................ TTL level (0 to 5 V) modulated infrared control from 30 kHz
RS-232 control RS-232 control (1-way) ............ ±5 V
Baud rate and protocol (RS-232) ...................... 57600 to 1200 (9600 default) baud (configurable);
IR learning frequencies..................................... 30 kHz to 62 kHz
IR learning distance ......................................... 4" (10 cm) to 14" (36 cm) from the front panel
Control — projeCtor/plasma (mlC 52 Ir)
Projector control port ....................................... (1) 3.5 mm direct insertion captive screw connector,
IR control ........................................................ TTL level (0 to 5 V) modulated infrared control from 30 kHz
IR learning frequencies..................................... 30 kHz to 62 kHz
IR learning distance ......................................... 4" (10 cm) to 14" (36 cm) from the side panel
General
External power supply ...................................... 100 VAC to 240 VAC, 50/60 Hz, external, autoswitchable;
Power input requirements ................................ 12 VDC, 0.15 A
Rack mount ..................................................... No, but wall- and furniture-mountable
Enclosure type ................................................ High-impact plastic or metal
Enclosure dimensions
MLC 52 faceplate ........................................ 4.5" H x 2.75" W x 0.13" D (11.4 cm H x
MLC 52 VC faceplate ................................... 4.5" H x 4.6" W x 0.1" D (11.4 cm H x
Device............................................................. 2.5" H x 1.6" W x 1.5" D (6.4 cm H x 4.1 cm W x
Product weight ................................................ 0.2 lbs (1 kg)
Shipping weight ............................................... 3 lbs (2 kg)
Vibration ........................................................ ISTA 1A in carton (International Safe Transit Association)
Listings ........................................................... UL, CUL
Compliances ................................................... CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF .............................................................. 30,000 hours
Warranty ........................................................ 3 years parts and labor
NOTE: All nominal levels are at ±10%
Extron Electronics, USA
1230 South Lewis Street
Anaheim, CA 92805
800.633.9876 714.491.1500
FAX 714.491.1517
© 2007 Extron Electronics. All rights reserved. All trademarks mentioned are the property of their respective owners.
(tip-ring-sleeve)
sleeve = GND
®
Extron's Simple Instruction Set (SIS )
™
connector, 6 pole for IR and 1-way RS 232
control (port is shared between power input and
IR and 1-way RS-232 projector control)
up to 1 MHz
8 (default) or 7 data bits;
1 stop bit (±5 V); no parity (default), or even or odd parity
6 pole for IR (port is shared with power input)
up to 1 MHz
to 12 VDC, 1 A, regulated
7.0 cm W x 0.3 cm D) (1 gang)
11.7 cm W x 0.3 cm D) (2 gang)
3.8 cm D) (Depth excludes connectors and buttons.)
Extron Electronics, Europe
Beeldschermweg 6C, 3821 AH Amersfoort
The Netherlands
+800.3987.6673 +31.33.453.4040
FAX +31.33.453.4050
General (Cont.)
Model Version Description
MLC 52 IR IR Control - Black & White......................................................... 60-744-02
MLC 52 RS IR and RS-232 Control - Black & White ...................................... 60-744-12
MLC 52 IR VC IR and Volume Control - Black & White ...................................... 60-745-02
MLC 52 RS VC IR, RS-232, and Volume Control - Black & White ........................ 60-745-12
Optional Accessories
CFG Cable 9 DB Female-2.5 mm TRS Config Cable - RS Version Only ......... 70-335-01
IPL TS 2 Two Serial Port IP Link Ethernet Control Interface ....................... 60-544-01
IR Link Wall-Mountable IR Signal Repeater ............................................ 60-404-02
IR Sensor Remote IR Receiver .................................................................. 70-223-01
MLM 52 VC Two-Gang Wall Mounting Kit with Volume Control - Black & White 70-527-02
MLM 52 VC Two-Gang Wall Mounting Kit with Volume Control - Black Metal .. 70-538-02
MLM 52 VC Two-Gang Wall Mounting Kit with Volume Control - White Metal .. 70-538-03
MLM 52 1GWP Metal One-Gang Wall Mounting Kit for the
MLC 52 Series - Black ............................................................. 70-498-02
Included Accessories
12V, 1A
power supply 100-240VAC, 50/60Hz, to 12VDC,1A, wire ................................ 70-055-01
MLC 52 Series
Button Labels Text and Icon Labels ................................................................. 33-1262-01
International Labels MediaLink International Faceplate Labels ................................... 33-1167-0X
IR Emitter and
Shield Kit IR Emitter Kits .......................................................................... 70-283-01
Plastic Mud Ring Black & White .......................................................................... 70-519-X1
Specifications are subject to change without notice.
Extron Electronics, Asia
135 Joo Seng Rd. #04-01
PM Industrial Bldg.
Singapore 368363
+65.6383.4400 FAX +65.6383.4664
M L C 5 2
Part Number
Extron Electronics, Japan
Kyodo Building, 16 Ichibancho
Chiyoda-ku, Tokyo 102-0082
Japan
+81.3.3511.7655 FAX +81.3.3511.7656
07-05
68-1439-01
REV. A
