Control Panel

10
Using the Control Panel
1 Light LED
2 Temp LED
Four Directional
3
Select Keys
4 Enter
5 IR Receiver
6 Re-Sync
Power /
7
Standy LED
8 Keystone
9 Menu
10 Source
Introduction
1 2 3 4
9 8
Indicate the projector light status.
Indicate the projector temperature status.
Use
adjustments to your selection.
Confirm your item selection.
Receive the remote control signal.
Automatically synchronize the projector to the
input source.
Press to turn the projector on or off (see "Power
On/Off the Projector" section on pages 14-15).
Indicate the projector power status.
Use
tilting the projector. (±40 degrees)
Press to launch the on-screen display (OSD)
menu. To exit OSD, press the key again.
Press to select an input signal.
7
to select items or make
to adjust image distortion caused by
5
6
11
