SERVICE MANUAL

Date
2012.05.24
2012.10.12
Prepared:Cherry
ZW210ST/ZX210ST
Revise Version
V1.0
V2.0
Copyright Oct 2012 All Rights Reserved
Checked:Amy/Alick
Initial Issue
Update the SSD1938 FW upgrade method
after FW Ver.1.0.1.5
Description
Approved: CC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZW210ST and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Optoma ZW210ST

Summary of Contents for Optoma ZW210ST

  • Page 1: Service Manual

    SERVICE MANUAL ZW210ST/ZX210ST Date Revise Version Description 2012.05.24 V1.0 Initial Issue Update the SSD1938 FW upgrade method 2012.10.12 V2.0 after FW Ver.1.0.1.5 Copyright Oct 2012 All Rights Reserved Prepared:Cherry Checked:Amy/Alick Approved: CC...
  • Page 2 Preface This manual is applied to ZW210ST/ZX210ST projection system. The manual gives you a brief description of basic technical information to help in service and maintain the product. Your customers will appreciate the quick response time when you immediately identify problems that occur with our products.
  • Page 3 ZW210ST/ZX210ST Comparison List Parts ZX210ST ZW210ST IO Cover Module 70.8NP15GR01 70.8NQ07GR01 Main Board 80.8NP01G001 80.8NQ01G001 Daughter Board 80.8NP06G001 80.8NQ06G001 48.8CQ01G003 48.8EJ01G001 Engine 70.8NP13GR01 70.8NQ06GR01 Confidential ZW210ST/ZX210ST...

  • Page 4: Table Of Contents

    Disassemble Rod Module 2-12 Disassemble Driver Board 2-13 Disassemble LD Module&Combiner Module 2-14 Disassemble LVPS 2-19 Disassemble Speaker Module 2-20 Disassemble Bottom Cover Module 2-21 Re-write Projector Hour 2-22 Repair Action 2-23 Chapter 3 Troubleshooting LED Lighting Message Main Procedure ZW210ST/ZX210ST Confidential...
  • Page 5 Section 2: MCU Firmware Upgrade Equipment Needed Setup Procedure 5-10 MCU Firmware Upgrade Procedure 5-12 Check MCU FW version 5-13 Section 3: SSD1938 Firmware Upgrade 5-14 Equipment Needed 5-14 Read MAC Address 5-15 Setup Procedure 5-16 Firmware Upgrade Procedure 5-18 Confidential ZW210ST/ZX210ST...
  • Page 6 Chapter 6 EDID Upgrade EDID Introduction Equipment Needed Setup Procedure EDID Key-In Procedure Appendix A Exploaded Overview Appendix B Serial Number System Definition PCBA Code Definition ZW210ST/ZX210ST Confidential...

  • Page 7: Chapter 1 Introduction

    ● +/- 12 degree is for system angle of V-keystone ●YM23L (ZX210ST) Projection lens ●YM37L (ZW210ST) ● 0.55” XGA, S450, Dark Chip 3 (ZX210ST) 0.65” WXGA, S450, Dark Chip 3 (ZW210ST) DMD Chip &Number of active dots ● Number of active dots:1280x800(ZW210ST) 1024x768(ZX210ST) System controller ●...

  • Page 8: Compatible Mode

    640 x 400 37.9 85.1 720 x 400 31.5 720 x 400 37.9 720 x 576 720 x 576 640 x 480 31.5 640 x 480 640 x 480 37.9 72.8 640 x 480 37.5 640 x 480 43.3 Confidential ZW210ST/ZX210ST...
  • Page 9 1280 x 768 1280 x 768 WXGA-800 1280 x 800 1280 x 1024 SXGA 1280 x 1024 1280 x 1024 91.1 SXGA+ 1400 x 1050 UXGA 1600 x1200 1920 x 1080 33.8 HDTV 1920 x 1080 28.1 1920 x 1080i ZW210ST/ZX210ST Confidential...
  • Page 10 1280 x 720p 720 x 576 31.3 720 x 576i 720 x 576p SDTV 720 x 480 31.5 720 x 480i 720 x 480p ZW210ST ● Signal Resolution �requency H.(KHz ) Refresh Rate(Hz) NTSC 15.734 15.625 640 x 350 31.5 640 x 350 37.9...
  • Page 11 1280 x 720 1280 x 720p 1280 x 720p 720 x 576i 720 x 576p SDTV 720 x 480i 720 x 480p Note: If the Computer Compatibility supportive signal is different from User’s Manual, please refer to User’s Manual. ZW210ST/ZX210ST Confidential...

  • Page 12: Equipment Needed & Product Overview

    * Note: - If you need to replace the main board, you have to get into service mode and record the LED usage hour. please refer to section 2-12. - The disassemble procedure for ZW210ST/ZX210ST is the same,we take ZX210ST as an example here.

  • Page 13: Disassemble Top Cover Module &Key Pad

    2-2 Disassemble Top Cover Module and Key Pad 1.- Unscrew 4 screws on the bottom side (as yellow circles) - Tear off the label on the bottom side,and unscrew 1 screw under it (as red circle) 2. - Disassemble the Top Cover(as yellow arrow direct).
  • Page 14 4. Separate the keypad and the keypad board. keypad board. . Keypad Board Keypad 5. Unscrew 4 screws on the focus ring (as yellow circles) Top Cover Focus Ring ZW20ST/ZX20ST Confidential...

  • Page 15: Disassemble Io Cover Module

    2-3 Disassemble IO Cover Module 1. Unscrew 4 screws (as yellow circles). 2. - Take off the mylar (as green square). - Unplug the fan connector from the main board(as yellow circle). 3.- Unscrew 4 screws (as yellow circles). - Separate the Fan Rubber and the Fan. ZW20ST/ZX20ST Confidential...

  • Page 16: Disassemble Front Cover Module

    2-4 Disassemble Front Cover Module 1.- Unscrew 3 screws (as yellow circle) and unplug 2 connectors (as green square). - Disassemble the Front Cover(as yellow arrow direct) 2.- Unscrew 2 screws (as yellow circles). - Separate the IR holder and the IR Board. IR Board ZW20ST/ZX20ST Confidential...
  • Page 17 3. - Unscrew 2 screws (as red circle) to disassemble the Fan module. - Separate the Fan Shilding and Fan Rubber and the Fan. ZW20ST/ZX20ST Confidential...

  • Page 18: Disassemble Main Board Module

    2-5 Disassemble Main Board Module 1. Unscrew 4 screws (as red circle) to disassemble the EMI Cover. 2. Unplug all connectors (as yellow squares in P2-8). 3. - Unscrew 4 screws (as blue circles) - Unplug the connector (as blue square) to disassemble the Main Board Module.
  • Page 19 A&B C D E F G&H Please refer to the table as below for details of each connector. ZW20ST/ZX20ST Confidential...
  • Page 20 5. Unscrew 6 screws (as yellow circles) to disassemble the Main Board. 6. Unplug the connector (as yellow square) to separate the main board and the daughter daughter board. Main Board Daughter Board ZW20ST/ZX20ST Confidential...

  • Page 21: Disassemble Fan

    2-6 Disassemble Fan 1. - Take off the Fans. Note: Care the direction about how to place the fan (as yellow squares). Separate the Fan Rubber and the Fan. ZW20ST/ZX20ST Confidential 2-0...

  • Page 22: Disassemble Engine Module

    2-7 Disassemble Engine Module 1.- Unscrew 4 screws (as yellow circle) to disassemble ROD cover. - Unscrew 6 screws (as red circle) to disassemble Engine Module. Engine Module 2.- Tear off the EMI mylar (as yellow square). - Unscrew 2 screws (as yellow circle) to disassemble Heat Sink and DMD Module.
  • Page 23 3. Rotate the screw (as yellow square) 90° counterclockwise to disassemble the DMD Board and DMD Chip. ZW20ST/ZX20ST Confidential 2-2...

  • Page 24: Disassemble Driver Board

    2-8 Disassemble Driver Board 1.- Unscrew 3 screws (as yellow circle). - Unplug 1 connector (as green square). Driver Board ZW20ST/ZX20ST Confidential 2-3...

  • Page 25: Disassemble Ld Module&Combiner Module

    2-9 Disassemble LD Module and Combiner Module 1. Unscrew 5 screws (as yellow circle) to disassemble the LD and Combiner Module. ZW20ST/ZX20ST Confidential 2-...
  • Page 26 2. Unscrew 1 screw (as yellow circle) to disassemble Light Sensor and unplug 2 connectors (as green square). LD and Combiner Module Red LED Cable Blue LED Cable Light Sensor Board 3. Unscrew 2 screws (as yellow circle) to disassemble the LD Module. ZW20ST/ZX20ST Confidential 2-15...
  • Page 27 LD Module 4. Unscrew 2 screws (as yellow circle) to disassemble Blue LED. ZW20ST/ZX20ST Confidential 2-...
  • Page 28 5.Unscrew 2 screws (as yellow circle) to disassemble Red LED. 6. Unscrew 2 screws (as yellow circle) to disassemble Phosphor wheel cover. 7. Unscrew 2 screws (as red circle) to disassemble Phosphor wheel module. ZW20ST/ZX20ST Confidential 2-17...
  • Page 29 Combiner Module Phospher wheel Module 8. Unscrew 1 screw (as yellow circle) to disassemble Photo sensor board. Phospher wheel Photo sensor board ZW20ST/ZX20ST Confidential 2-18...

  • Page 30: Disassemble Lvps

    2-10 Disassemble LVPS Module 1. Unplug 2 connectors (as green square). 2. Unscrew 7 screws (as yellow circle) to disassemble LVPS Module. 3. Unplug 1 connector (as yellow square) to disassemble Interlock Switch Module. Interlock Switch LVPS ZW20ST/ZX20ST Confidential 2-...

  • Page 31: Disassemble Speaker Module

    2-11 Disassemble Speaker Module 1.- Unscrew 4 screws (as red circle) to disassemble Speaker Module. - Take off the malar (as green square). 2. Separate the speaker rubbers and speakers. ZW20ST/ZX20ST Confidential 2-20...

  • Page 32: Disassemble Bottom Cover Module

    2-12 Disassemble Bottom Cover Module 1. Unscrew 4 screw (as yellow circles) 2. Unscrew 4 screws (as red circles) to disassemble bottom shielding and unscrew 1 hex screw (as yellow circle). Bottom shieiding Bottom cover ZW20ST/ZX20ST Confidential 2-2...

  • Page 33: Re-Write Projector Hour

    2-13 Re-write Projection Hour 1. Get into service mode - Press (Power→Left→Left→Menu) to get into service mode. 2. Choose "ADC/DEC Color" to re-write the usage hour back to previous usage hour. 3. Choose "Exit" Note: left key = decrease projector hour right key =increase projector hour ZW20ST/ZX20ST Confidential...

  • Page 34: Repair Action

    2-14 Repair Action Change Parts Software Description Repair Main Engine Daughter Combiner Phospher Action Fan Firmware Board Module Board Module wheel page System Chapter 5- Firmware Section 1 Update Chapter 4-4 Calibration EDID Chapter 6 OSD Reset Chapter 4-6 Re-write Chapter LED Hours 2-3...

  • Page 35: Chapter 3 Troubleshooting

    Chapter 3 Troubleshooting Note: Opening the top cover to do troubleshooting are forbidden. 3-1 LED Lighting Message POWER/ STANDBY Temp-LED Light-LED Message (Blue/Red) (Yellow Green) (Amber) Standby State (Input power cord) Power on Flashing (Warming) Blue Light lighting Blue Flashing Power off (Cooling) Blue Flashing...

  • Page 36: Main Procedure

    3-2 Main Procedure Symptom Procedure - Ensure the Power Cord and AC Power Outlet are securely connected. - Ensure all connectors are securely connected and aren’t broken. - Check FPC cable between Keypad Board and Main Board. No Power - Check Interlock Switch - Check LVPS - Check Driver board - Check Keypad Board...
  • Page 37 Symptom Procedure - Do “Factory Reset ” of the OSD Menu - Ensure that the signal cables and source work well - Check Main Board - Check Phospher wheel - Check Phospher wheel Image Flicker - Check Driver Board - Check Daughter Board - Check Photo sensor board - Ensure the Projection Screen without dirt - Ensure the Projection Lens is clean...
  • Page 38 - If you forget the Password, please do the following steps to get the Universal Password: (1) When you turn on the projector, the message “Enter Security Code” appears. Please Input the “Current Security Code 8642” by Remote Control, then press “Enter”. (2) Press “Menu”...

  • Page 39: Function Test & Alignment Procedure

    4-2 Test Condition - Circumstance brightness: Dark room less than 2.0 lux. - Inspection distance: 4:3(0.8~1.2 m) 16:10(0.8~1.2 m) - Screen size:77 inches diagonal (ZX210ST) 87.2 inches diagonal (ZW210ST) Zone Definition < Figure: Zone A(as green line) Definition > ZW20ST/ZX20ST Confidential...

  • Page 40: Vga Port Test

    4-3 I/O Port Test 4-3-1 VGA Port Test 1. Frequency and Tracking Boundary Procedure - Test equipment: video generator - Test signal: ZW210ST1280x800@60Hz ZX210ST1024x768@60Hz @60Hz - Test Pattern: Genera l-1 - Check and see if the image sharpness is well performed.
  • Page 41 Criteria - Please refer to Pixel specification table. Gray 10 5. Dark Blemish Procedure - Test equipment: video generator - Test signal: ZW210ST 1280x800@60Hz ZX210ST 1024x768@60Hz - Test Pattern: Blue 60 Blue 60 Inspection item - Dark blemish check. Criteria...
  • Page 42 Pixel specification (for ZW210ST) Order Symptom Pattern Criteria A≤ 4 Major Dark Blemish Blue 60 (diameter < 1 inch) A≤ 4 Major Bright Blemish Gray 10 pattern (diameter < 1 inch) Bright Pixel Gray 10 pattern A = 0 Dark Pixel White pattern A ≤...
  • Page 43 6. Focus Test Procedure - Test equipment: video generator - Test signal: ZW210ST1280x800@60Hz ZW210ST1280x800@60Hz ZX210ST1024x768@60Hz - Test Pattern: Full screen Inspection item - Focus check Criteria - From screen 1.2M via visual to check focus, look at the entire screen, focus shall be clear,crisp and sharp over the entire surface of the display pattern.
  • Page 44 7. Color Performance Procedure - Test equipment: video generator. - Test signal: ZW210ST 1280x800@60Hz ZW210ST 1280x800@60Hz ZX210ST 1024x768@60Hz - Test Pattern: Master, 64 gray RGBW or 32GRAYS Inspection item - Check if each color level is well-functioned. Master - Color saturation Criteria - Screen appears normal.

  • Page 45: Hdmi Test

    4-3-2 Composite Video Port And AudioTest Procedure - Test equipment: DVD player - Test signal: CVBS Inspection item - Audio performance test Inspection Distance - 4:3(0.8~1.2 m) 16:10(0.8~1.2 m) Criteria - Check the sound from speaker. - Check "Volume" is normal - Check "Mute"...

  • Page 46: Calibration

    4-3-5 SD Card /U disk Test Procedure - Test equipment: SD Card/U disk - Test signal:ZW210ST 1280x800@60Hz ZX210ST 1024x768@60Hz - Turn on the projector and plug SD Card SD Card/U disk into the projector. - Ensure the image and audio are well performed and the color can not discolor.

  • Page 47: Adc Calibration

    Engine Module ,or upgrading firmware is changed, PC Calibration should be done firmware is changed, PC Calibration should be done is changed, PC Calibration should be done as well. (1) Test signal: ZW210ST ZW20ST 1280x800@60Hz ZX210ST 1024x768@60Hz (2) Test Pattern: 94%W/6.4%W - Note (1) ���alibration pattern should be in full screen mode.
  • Page 48 3. LED calibration Note: - If the color is abnormal after replacing engine module or main board, please e�cute “L�� calibration” as below procedure. - ���L200 RS232 ���able PN: 42.00201GR01 1.First method without CL200:Reset calibration data Procedure - Please press “Power”->”Left”->“Left”->“Menu” “Left”->“Menu”...
  • Page 49 4-3-9 RJ45 Port Test Note:The RJ45 Port Test procedure for ZX210ST/ZW210ST are the same,we take ZX210ST as an e�ample here. 1. Write Down Projector IP Write down the IP address: 192.168.100.10. 2. Network Setting (1) Open the “Local area connection” ,choose “properties”.
  • Page 50 (4) Click “OK”. 3. Read Projector Information (1) Connect the PC and the Projector with LAN Cable. (2) Click “Internet Explorer”. (3) Write the IP address: http://192.168.100.10 (4) Then the information will be shown on the web. ZW20ST/ZX20ST Confidential 4-2...

  • Page 51: Run In Test

    4-5 Run In Test - Temperature: 29°C~35°C - Circumstance brightness: Normal environment - Screen size: No concern - Display mode: ECO mode After repairing each unit, it should be Run-in (refer to the below table). Symptom Run-in Time Normal repair 2 hours 4 hours Auto shut down...

  • Page 52: Test Inspection Procedure

    Press power→ left → left → menu Choose Burn In Test > enter Lamp On (Min) Press right key to adjust the time (50) Lamp Off (Min) Press right key to adjust the time (10) Set Burning cycle Press right key to adjust the cycle After setting up the time, choose ''Start Burn In Mode'' and press "Menu"...

  • Page 53: Firmware Upgrade

    - Firmware (*.img) - library (library 10.5) Hardware : - Projector - Power Cord - Cable USB-A to USB-B(42.00281G102) - PC or Laptop Note: - The FW upgrade procedure for ZW210ST/ZX210ST are the same,we take ZX210ST as an example here. ZW20ST/ZX20ST Confidential...

  • Page 54: Setup Procedure

    5-1-2 DLP Composer Lite Setup Procedure 1. Choose "DLP Composer Lite V10.5 Setup" program. 2. Click "Next". 3. Read License Agreement. - Choose " I accept and agree to be bound by all the terms and conditions of this License Agreement". - Click "Next".
  • Page 55 5. Click "Next". 6. Click "Next". 7. Click "Finish". 8. Restart the computer. ZW20ST/ZX20ST Confidential...
  • Page 56 5-1-3 Firmware Upgrade Procedure 1. Set-up - Hold on "Power" and "Menu" and plug in power cord to get into FW download mode. - Once all LED light on,release "Power" and "Menu" button. - Insert USB cable to projector&PC 2. - Found new hardware wizard will appear on the screen.
  • Page 57 3. Execute the DLP Composer Lite. Execute the DLP Composer Lite. 4. Click "Edit" and "Perferences". ZW20ST/ZX20ST Confidential...
  • Page 58 5. Click “Library.” - Click the “browse” button and navigate to the directory where you put the library file 6. Click "Communications ",then select "USB" 7. Choose "Flash Loader". - Click "Browse" to search the firmware file (*.img). - Click "Open" ZW20ST/ZX20ST Confidential...
  • Page 59 8. Selete the item skip Boot Loader Area - Select "32KB". - Click "Reset Bus" to erase the flash memory. 9.- If the firmware is ready, click "Start Download" to process the firmware upgrade. - Click " Yes" to erase the flash memory. 10.
  • Page 60 11. Re-plug in power cord and power on the projector. Get into the service mode (power-->left-->left-->menu) to check the firmware version. ZW20ST/ZX20ST Confidential...

  • Page 61: Mcu Firmware Upgrade Procedure

    Section 2: MCU Firmware Upgrade Procedure 5-2-1 Equipment Needed Software : - ICP Programmer(Setup,Coretronic ICP Programmer,v5.41.exe) - USB-to-Serial COM port Driver (PL2303_Prolific_DriverInstaller_v110.exe) - Program file (*.TPJ) Hardware : - Projector - Power Cord - ICP FIXTURE (SP.8JC08G001) - PC or Laptop ZW20ST/ZX20ST Confidential...

  • Page 62: Setup Procedure

    5-2-2 Setup Procedure Install ICP Utility 1. Double click "Setup,Coretronic ICP Programmer, v5.41.exe". 2. Click "Next". 3. Click "Next". 4. Click "Next". ZW20ST/ZX20ST Confidential 5-0...
  • Page 63 5. Click "Finish" to end Coretronic ICP Programmer installed. Install PL2303_Prolific_Driver 6. Double Click "PL2303_Prolific_Driver Installer_v110.exe" 7. Click "Next". 8. Click "Finish" to end Click "Finish" to end PL2303_Prolific_Driver installed. ZW20ST/ZX20ST Confidential 5-...
  • Page 64 5-2-3 Upgrade Procedure 1. Connect the PC (VGA in) and projector by ICP FIXTURE and plug in the power cord. 2. Select "Start" -->"Coretronic Tools" -->"Coretronic ICP Programmer V5.41" to run "Coretronic ICP Programmer.exe”. 3. Click “Load Proj” to open the “TPJ” file which you will upgrade MCU firmware file.
  • Page 65 4. Click “ Update Chip” to upgrade the MCU firmware. 5. Finish - When MCU FW upgrade process is finished, "PASS" will be shown. 6. Re-plug in power cord and Power on the projector. Get into the service mode to check the MCU firmware version.
  • Page 66 Section 3: SSD1938 Firmware Upgrade Procedure 5-3-1 Equipment Needed Software : - MagusCore_Download_Tool_v3.0.7 - SSD1938 Firmware file (Download.zip) Hardware : - Projector - Power Cord - USB Cable mini USB to USB (A) (42.00284G001) - PC or Laptop Note:Before upgrading this FW,please record the Lan MAC address from the website firstly.

  • Page 67: Read Mac Address

    5-3-2 Read MAC Address 1. Network Setting (1) Open the “Local area connection” ,choose “properties”. (2) Select “Internet protocol (TCP/IP)” (3)- Modify the IP address to 192.168.100.101, and modify Subnet mask to 255.255.255.0 - Click “OK” (4) Click “OK”. 3. Read MAC Address (1) Connect the PC and the Projector with LAN Cable.

  • Page 68: Setup Procedure

    5-3-3 Setup Procedure 1. Set-up - Hold on "Power" and "Menu" and plug in power cord to get into FW download mode. - Once all LED light on,release "Power" and "Menu" button. - Insert Mini USB cable to projector&PC 5-3-4 Install USB Driver 1.
  • Page 69 3. Select the “USB_driver”,then click “OK”. Note: If the PC is Win7 system,please select the Win7_driver 4. Wait for several seconds. 5. Click “Finish”. Note: - If “Found New Hardware Wiszard” picture appear again, repeat step 2 to install USB Drivier. ZW20ST/ZX20ST Confidential 5-...
  • Page 70 5-3-5 Firmware Upgrade Procedure 1. - Double click the MagusCore_Download_ Tool_v3.0.7 - Put the firmware file "download" which need to upgrade to MagusCore_ Download_ Tool_v3.0.7 2. Execute “USB.exe”. Note:- "Standard Input/Output" will appear to show the firmware upgrade process when execute “USB.exe”. - If the Error message appear when "Standard Input/Output"...
  • Page 71 4. Select "setup_SSD1938 _T02_PPU0F" 5. Double click "config.ini" 6. Select "Option" ,then select "Platform",then select "SSD1938 _T02_PPU0F". 7. Select "Option" ,then select "Operation", then select "1st Flash+MAC". ZW20ST/ZX20ST Confidential 5-...
  • Page 72 8. Select "File" ,then select "Set Source File Directory". 9. Select "download" ,then double click it. 10. Click "Done" 11. Wait a few minutes,then key in the MAC address you write down before. Note:The ":"on the MAC address need not to key in .
  • Page 73 12. When message “done” appears,the firmware will upgrade sucess. Note: "Standard Input/Output" can also show the result of the firmware upgrade. 13. Re-plug in power cord and power on the projector. After 3min ,the system upgrading OK,please get into the service mode to check the SSD1938 firmware version.

  • Page 74: Edid Upgrade

    Note: - If a display device has digital input ports, like DVI or HDMI, but without EDID in its main board, the display device will show no image while the input source is digital signal. -The EDID Upgrade procedure for ZW210ST/ZX210ST are the same, we take ZX210ST as an example here. ZW20ST/ZX20ST...
  • Page 75 6-2 Equipment Needed Software - EDID Program (Generic V0.81) - EDID File (*.ini) Hardware - Projector - Generic Fixture (80.00001.001) for EDID Key-in - Power Cord - RS-232 9 Pin Cable (pin to pin, F-M) (42.83C07G001) - Monitor - PC - VGA cable (42.87305G102) - Power adapter (47.57803G001) and power cord (42.53506G002) for fixture - HDMI to DVI Cable(42.00256G001)
  • Page 76 6-3 Setup Procedure 1. Connect all ports (1) Connect P1 of Fixture with COM Port of PC/Laptop by RS232 Cable. (2) Connect P2 of Fixture with VGA port of Projector by VGA Cable. (3) Connect P3 of Fixture with DVI port ,and connect Power CNN HDMI port of Projector.
  • Page 77 6-4 EDID Key-In Procedure 1. Execute EDID Program (1) Click on "EDID" to execute EDID program. 2. Process (1) Check the COM port is COM4" (Select the COM port which you are using). (2) Click the Model button. (3) Choose the source file "*.ini" and then open it.
  • Page 78 4.- "Please change the cable to HDMI" will be shown on the screen. - Please press "Ok" button. 5. Finish (1) "OK" will be shown on the screen. 6. Read EDID information (1) In the Read item,select "Analog" and "Trans". (2) Please press "Read"...
  • Page 79 Appendix A Note:The parts marked "V" is the recommend spare parts list. Confidential ZW210ST/ZX210ST...
  • Page 80 SCREW PAN MECH M3*8 BLACK “GREEN” SCREW PAN MECH M2*5 Ni NYLOK SCREW PAN MECH M2.6*6 Ni NYLOK SCREW ISO M3*7mm NI PH W/LW SCREW PAN MECH M4*5 COLOR W/TOOTH WASHER Cr3+ ASSY ENGINE SYSTEM WXGA ZW210ST ASSY ENGINE MODULE FOR 8NP(SERVICE) Confidential ZW210ST/ZX210ST...
  • Page 81 BOTTOM COVER Confidential ZW210ST/ZX210ST...
  • Page 82 DMG HOLDER PC FOR HYBRID SPEAKER RUBBER RIGHT ZX210ST SPEAKER RUBBER LEFT ZX210ST GLUE RED FOR THREAD LOCKER(PRE-ASSY) LOCTITE:271 BOTTOM COVER SHIELDING SECC HYBRID BUY ASSY BOTTOM COVER ZX210ST SCREW PAN MECH M3*5 Ni SCREW CAP MECH M2*3 Ni NYLOK Confidential ZW210ST/ZX210ST...

  • Page 83: Top Cover

    TOP COVER ITEM DESCRIPTION Supply FFC 20P P=0.5 M/B TO DOCK/B 130mm DV20 KEYPAD P+R ZX210ST BUY ASSY TOP COVER ZX210ST PCBA KEYPAD BD FOR ZX210 PROJECTOR SCREW PAN MECH M3*5 Ni Confidential ZW210ST/ZX210ST...
  • Page 84 FRONT COVER ITEM DECRIPTION Supply BUY ASSY FRONT COVER ZX210ST PCBA IR BD FOR ZX210ST PROJECTOR Confidential ZW210ST/ZX210ST...
  • Page 85 IO COVER ITEM DESCRIPTION Supply IO LABEL ZX210ST 7010 AXIAL FAN F TYPE, RoHS2.0 FAN RUBBER ZX210ST STEP SCREW M3 ZX210ST BUY ASSY IO COVER ZW210ST ASSY IO COVER MODULE FOR 8NP(SERVICE) Confidential ZW210ST/ZX210ST...

  • Page 86: Lvps Module

    LVPS MODULE ITEM DECRIPTION Supply CABLE W.A. 14P #24 150mm M/B TO LVPS Hybrid WITH EMI CORD CABLE W.A. 16P #24 125mm M/B TO LVPS 2400MP AC INLET BRACKET SECC HYBRID POWER SUPPLY, AD-301W, INLET, 154*109.5, DL, FUSE MODIFY Confidential ZW210ST/ZX210ST...
  • Page 87 SHEILDING MODULE Confidential ZW210ST/ZX210ST...
  • Page 88 HEX SCREW L=16 M3 Cu 2300MPX BUY ASSY TOP SHIELDING ZX210ST BUY ASSY MB SHIELDING ZX210ST PCBA MAIN BD FOR ZW210ST PROJECTOR PCBA MAIN BD FOR ZX210ST PROJECTOR PCBA DAUGHTER BD FOR ZW210 PROJECTOR PCBA DAUGHTER BD FOR ZX210 PROJECTOR...
  • Page 89 ENGINE&LD&COMBINER MODULE Confidential ZW210ST/ZX210ST...
  • Page 90 0.55” XGA 2xLVDS SERIES 450 DMD -8 1076-603cB TI ASSY LD MODULE FOR 8NP(SERVICE) ASSY PHOSPHOR WHEEL MODULE K520 (SERVICE) PT54-RA-C21-MPF, DW 615NM ,HYBRID SSI, LUMINUS, PEAK LUMEN>1000 LM PT54,BLUE LED,Standard Die Config,D52 for NEC NP- L50W,Luminus LED PAD FUJIPOLY Sarcon XR-Hj 24.3X14.7X0.5mm Confidential ZW210ST/ZX210ST...
  • Page 91 Confidential ZW210ST/ZX210ST...
  • Page 92 DECRIPTION Supply D.C. ZX210ST LABEL PREVENT OPEN DIM28MM LABEL CARTON 108*92 BLANK PALLET LABEL (W)100mm X(H)53mm FOR OPTOMA MODEL AK LABEL 3”*3” BLANK SPEC LABEL BLANK PD120 PACKING TAPE 72MM FOR OPTOMA HANDLE BAR 2. PE HD70 HANDLE BAR 1.PE HD70...
  • Page 93 Serial Number Format for Projector (take ZX210ST as example) AAAAA C 0001 Q = Optoma 8NP = Project Code (ZX210ST) 2 = Last number of the manufacture year (ex:2012= 2) 15 = week of the manufacture year (ex:the fifteenth week of the...
  • Page 94 II.PCBA Code Definition PCBA Code for Projector XXXXXXXXX EEEE Vendor Code Firmware Version MB Version Date Code Confidential ZW210ST/ZX210ST...
