Exmark Lazer ZXS Operator's Manual page 26

ECS HANDLE DRIVE LEVER LINKAGE INSTALLATION
4.1.6 Check for loose hardware.
Service Interval: Daily
a) Stop engine and wait for all moving parts to stop. Remove key or spark plug
wire(s).
b) Visually inspect machine for any loose hardware or any other possible
problem. Tighten or replace any hardware before operating.
4.1.7 Service pre-cleaner element and air cleaner.
Service Interval: See Engine Owners Manual
a) Stop engine and wait for all moving parts to stop. Remove key or spark plug
wire(s).
b) See engine owners manual for cleaning instructions.
4.1.8 Change engine oil.
Service Interval: See Engine Owner's Manual
NOTE: Change oil after first five (5) hrs. of operation. Follow engine
manufacturer's recommendations for future oil changes.
a) Disengage PTO.
b) Stop engine and wait for all moving parts to stop. Remove key or spark plug
wire(s).
c) Drain oil while engine is warm from operation or if oil is to be changed after the
unit has been sitting for awhile, run engine for a few minutes to get it warm.
d) Remove the oil drain plug from the right hand side of the engine. Allow oil to
drain, replace drain plug.
e) Replace the oil filter per the engine owners manual. Clean around oil filter and
unscrew filter to remove. Before the new filter is installed, apply a thin coating
of oil on the surface of the rubber seal. Turn filter clockwise until rubber seal
contacts the filter adapter, then tighten filter an additional 2/3 to 3/4 turn.
f) Clean around oil fill cap and remove. Fill to specified capacity and replace
cap. Refer to Engine Owner's Manual for correct oil level and the SAE Grade
recommended by the manufacturer. Do Not overfill.
g) Start the engine and check for leaks. Stop engine and recheck oil levels.
FIGURE 9
- 21 -
