Exmark Lazer ZXS Operator's Manual page 20

(a)
(c)
DRIVE LEVER, NEUTRAL LOCK/PARK BRAKE LATCH OPERATION
3.3.5 Drive Wheel Engagement and Turning:
With drive levers in the "neutral" or "park brake" position, shift transmission into
desired gear. Squeeze both drive levers and move both neutral lock/park brake
latches from the "neutral" or "park brake" position to the "drive" position.
For straight ahead motion: Smoothly release both drive levers to engage drive
wheels.
For turning: Squeeze the right hand drive lever to turn right and squeeze left hand
drive lever to turn left (See Section 3.1.3).
3.3.6 Stopping the Unit:
Squeeze drive levers all the way back to engage brakes. Move neutral lock/park
brake latches into the "park brake" position and release drive levers. Shift
transmission into neutral.
3.3.7 PTO Engagement:
POTENTIAL HAZARD
♦ The rotating blades under the mower deck are
dangerous.
WHAT CAN HAPPEN
♦ Blade contact can cause serious injury or kill you.
HOW TO AVOID THE HAZARD
♦ DO NOT put hands or feet under the mower or mower
deck when the blades are engaged.
(b)
(d)
FIGURE 4
DANGER
- 15 -
