Thank you very much for purchasing the ZOOM
Please read this manual carefully to learn about all the functions of
the
so that you will be able to use it fully for a long time.
Keep this manual in a convenient place for reference when necessary.
A printed list of effect parameters is not included with the
Please download a copy from the ZOOM website. ! http://www.zoom.co.jp/downloads/
Copying or reproduction of this document in whole or in part without permission is prohibited.
OPERATION MANUAL
.
.
© ZOOM CORPORATION
If the
is not used for 10
hours, it will turn off automatically
by default.
If you want the power to stay ON all the time,
please see "4 To set the Power Management
function" on page 19 and set the value to OFF.
Advertisement
Table of Contents
Related Manuals for Zoom MultiStomp MS-50G
Summary of Contents for Zoom MultiStomp MS-50G
- Page 1 A printed list of effect parameters is not included with the function" on page 19 and set the value to OFF. Please download a copy from the ZOOM website. ! http://www.zoom.co.jp/downloads/ © ZOOM CORPORATION Copying or reproduction of this document in whole or in part without permission is prohibited.
-
Page 2: Table Of Contents
Contents Usage and Safety Precautions …………………… 3 Tapping the Tempo ……………………………… 16 Part Names ………………………………………… 4 Changing Various Settings ……………………… 18 Turning the Power ON ……………………………… 6 Updating the Firmware …………………………… 23 Adjusting Effects …………………………………… 8 Effect Types ……………………………………… 24 Selecting and Saving Patch Memories …………... -
Page 3: Usage And Safety Precautions
OFF and disconnect other cables. Contact the store where you bought the unit Do not drop, bump or apply excessive force to the unit. or ZOOM service with the following information: product model, serial number and specific Be careful not to allow foreign objects or liquids to enter the unit. -
Page 4: Part Names
DC9V AC adapter jack USB connector To power the unit from an outlet, Use to connect to a computer and connect an AD-16 adapter here update firmware (!P23). (!P6). INPUT jack OUTPUT jacks Connect a guitar. Connect to an amp or another effector. - Page 5 Parameter knobs Cursor keys From the left Parameter knob 1 [ Turn left and right to adjust the parameter. Press to open the MENU where you can remove and rearrange effects and make various settings (!P12, 18). You can also check the firmware version (!P22). Up and down cursor keys [ Parameter knob 2 [ Press to change the effect type.
-
Page 6: Turning The Power On
Plug a guitar cable into the INPUT jack. To turn the power ON Lower the amplifier’s volume all the way. Power the unit with batteries or an adapter. <When using batteries> Open the cover on the bottom of the unit and insert batteries in the compartment. - Page 7 Edit Screen shows parameter being edited Display information The Home Screen shows the current effect Effect type Page tabs Parameter names Virtual knob Parameter values HINT Graphic for selected effect Shows other effects are in this direction. adjusted, multiple page tabs will be shown. HINT parameter values.
-
Page 8: Adjusting Effects
Confirm that the Home Screen is shown. To select an effect type To turn an effect ON and OFF Press either Press HINT See step 2 of ”To add an effect” . (See page 12.) To adjust parameters NOTE Turn Adjusting Effects... - Page 9 To change the page Effect processing limit T h e a l l o w s y o u t o c o m b i n e 6 e ffe c t s a s yo u l i ke . Press However, if you combine effect types that require great amounts of...
-
Page 10: Selecting And Saving Patch Memories
Confirm that the Home Screen is shown. Select the patch memory to be saved with a new name. To select a patch memory Turn When shipped from the factory, the automatic patch Press memory saving function is active. As soon as a parameter is adjusted this change is automatically saved. -
Page 11: Changing Patch Memories With The Footswitch
Confirm that the Home Screen is shown. To cycle through patch memories in the list in order using the footswitch To add or remove patch memories to a list that the footswitch cycles through Open the MEMORY list. Open the MEMORY list. Press Press Change the patch memory. -
Page 12: Using 2 Or More Effects
Confirm that the Home Screen is shown. To remove an effect To add an effect Open the MENU. Open the ADD EFFECT UNIT screen. Press Press and hold either for 1 second Select DELETE EFFECT UNIT. Select the effect category. Turn Press Press any... - Page 13 Select the effect to move and ”lift” it. To scroll through the effects shown Turn When multiple effects are in use, scroll to change the (Select) visible one. Press either Press (Lift) HINT Shows the effect number counting from the right. Shows how many effects are in this direction.
-
Page 14: Using The Tuner
To activate the Tuner To change the tuner’s standard pitch Confirm that the Tuner Screen is open. Press Press hold for 1 second Turn NOTE A setting must be changed to make pressing and holding the footswitch activate Tap Tempo. (See page 18.) To select the tuner type Confirm that the Tuner Screen is open. -
Page 15: Chromatic Tuner
CHROMATIC To tune a guitar The chromatic tuner shows the nearest pitch name (semitone) and how far the input sound is from that pitch. Play the open string that you want to tune and tune it. Other tuner types Depending on the selected type, the nearest string Chromatic tuner name and how far the sound input is from that pitch The name of the nearest note and the pitch accuracy... -
Page 16: Tapping The Tempo
Delay effects and some modulation and filter effects can Tap the footswitch 2 or more times at the be synchronized to the tempo. Select an effect that can be desired tempo. synchronized, and set its Time, Rate or other parameter that can be synchronized to a or note value. - Page 17 To tap tempo by hand Open an effect that can be synchronized to the tempo on the Home Screen. (See page 8, 24.) Open the parameter editing screen. Press Tap the knob 2 or more times at the desired tempo. Press The ON/OFF indicator flashes in time with the tempo.
-
Page 18: Changing Various Settings
To change various settings To set the function activated by pressing and holding the footswitch Open the MENU. Set the function activated by pressing the footswitch Press continuously for 1 second to TUNER or TAP TEMPO. Select HOLD FOR TUNER/TAP from the SETTINGS menu. - Page 19 To set the tuner mode To set the Power Management function Select BYPASS/MUTE TUNER from the SETTINGS menu. Select POWER MANAGEMENT from the SETTINGS menu. Turn Turn Press Press Set the tuner mode Set the Power Management function. Turn Turn Press Press HINT...
- Page 20 To set the Auto Save function To select the battery type Select AUTO SAVE from the SETTINGS menu. Select BATTERY TYPE from the SETTINGS menu. Turn Turn Press Press Set the Auto Save function. Set the type of batteries used. Turn Turn Press...
- Page 21 To set the amount of time until the To adjust the display contrast backlight dims Select LCD BACKLIGHT from the SETTINGS Select LCD CONTRAST from the SETTINGS menu. menu. Turn Turn Press Press Set the amount of time until the backlight dims. Adjust the display contrast.
- Page 22 To view the firmware versions Open the MENU. Press Select VERSION. Turn Press The firmware version is shown. HINT for the latest firmware versions. Changing Various Settings...
-
Page 23: Updating The Firmware
Launch the firmware update application on To update the firmware your computer, and execute the update. NOTE While pressing both the up and down cursor keys, use a USB cable to connect the USB is being updated. connector to the computer. HINT While pressing both... -
Page 24: Effect Types
M-Filter of a Moog MF-101 low pass filter FLTR performance. and can be set in a wide range. ZOOM's unique noise reduction This special effect gives the Step cuts noise during pauses in sound a stepped quality. playing without affecting the tone. - Page 25 Matchless Hotbox pre-amplifier HotBox T Scream as a booster and has inspired with a built-in tube. numerous clones. ZOOM original unadorned clean Z Clean sound. OD/DIST Dist+ distortion+ effect that made This distortion effect boasts the distortion popular worldwide.
- Page 26 Tempo Tempo Category Effect type Effect explanation Category Effect type Effect explanation sync. sync. This simulates the sound of an Th i s e ffe c t a d d s a p h a s i n g Phaser early model of a class-A British variation to the sound.
- Page 27 Tempo Tempo Category Effect type Effect explanation Category Effect type Effect explanation sync. sync. This effect automatically adds This delay effect allows the use Vibrato ModDelay vibrato. of modulation. This effect adds sound 1 octave This analog delay simulation has Octave and 2 octaves below the original AnalogDly...
-
Page 28: Restoring The To Its Factory Default Settings
Press the footswitch to execute it. To execute the All Initialize function Press The All Initialize function restores all the factory default settings. NOTE Executing the All Initialize function will restore all the settings of the , including its patch memories, to factory defaults. -
Page 29: Troubleshooting
Set the type of battery being used to enable the remaining charge to be shown more Check shielded cables for defects. accurately (!P20). Use only a genuine ZOOM AC adapter (!P6). Due to the characteristics of the batteries, they might be used more quickly in cold. Troubleshooting... -
Page 30: Specifications
Maximum output level: Line +5dBm (with output load impedance of 10 k or more) Power AC adapter DC9V (center minus plug), 500 mA (ZOOM AD-16) Batteries About 7 hours of continuous operation using AA alkaline batteries 130.3mm(D) x 77 .5mm(W) x 58.5mm(H) -
Page 31: Tuner Types
Tuner Types String number / Note name Display Meaning GUITAR Standard tuning for guitars, including 7-string guitars OPEN A In open A tuning, the open strings make an A chord OPEN D In open D tuning, the open strings make a D chord OPEN E In open E tuning, the open strings make an E chord OPEN G... -
Page 32: Zoom Corporation
For more detailed information about recycling of this product, which the receiver is connected. please contact your local city office, your household waste disposal service or the shop where you purchased the product. ZOOM CORPORATION 4-4-3 Surugadai, Kanda, Chiyoda-ku, Tokyo 101-0062 Japan http://www.zoom.co.jp MS-50G - 5000-...
