Effect Types and Parameters
This document cannot be displayed properly on black-and-white displays.
© 2023 ZOOM CORPORATION
Manufacturer names and product names are trademarks or registered trademarks of their respective owners. The names are used only to illustrate sonic
characteristics and do not indicate any affiliation with the Zoom Corporation.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MULTISTOMP MS-50G+ and is the answer not in the manual?

Questions and answers

Related Manuals for Zoom MULTISTOMP MS-50G+

Summary of Contents for Zoom MULTISTOMP MS-50G+

  • Page 1 This document cannot be displayed properly on black-and-white displays. © 2023 ZOOM CORPORATION Manufacturer names and product names are trademarks or registered trademarks of their respective owners. The names are used only to illustrate sonic characteristics and do not indicate any affiliation with the Zoom Corporation.

  • Page 2: Table Of Contents

    Effect explanation overview Tempo synchronization possible icon Effect type Effect explanation Parameter range DELAY This long delay has a maximum length of 4000 ms. TIME Sets the delay time. 1 – 4000 SHORT, Sets the delay time range. LONG, MODE When metronome is chosen, the delay time is synchronized to the tempo.
  • Page 3 This is a limiter that suppresses signal peaks above a certain reference level. 10 – 70 Adjusts the output level. 0 – 80 OUTPUT ZOOM NOISE ZOOM's unique noise reduction cuts noise during pauses in playing without affecting the REDUCTION tone. GTRIN, DETCT Sets control signal detection level.
  • Page 4 Effect Types and Parameters [ DYNAMICS ] SLOW This effect slows the attack of each note, resulting in a violin-like performance. ATTACK TIME Adjusts the attack time. 1 – 50 CURVE Set the curve of volume change during attack. 0 – 10 TONE Adjusts the tone.
  • Page 5 Effect Types and Parameters [ FILTER ] GUITAR GRAPHIC This mono graphic equalizer has 7 bands that suit guitar frequencies. 100Hz Adjust to boost or cut 100 Hz. -12 – 12 200Hz Adjust to boost or cut 200 Hz. -12 – 12 400Hz Adjust to boost or cut 400 Hz.
  • Page 6 Effect Types and Parameters [ DRIVE ] ZEN O.DRIVE This models the sound of a Hermida Audio Zendrive. GAIN Adjusts the gain. 0 – 100 TONE Adjusts the tone. 0 – 100 VOICE Adjusts gain of high frequencies. 0 – 100 Adjusts the volume.
  • Page 7 Effect Types and Parameters [ DRIVE ] TB MK1.5 This is a classic fuzz effect. FUZZ ATTCK Adjusts the gain. 0 – 100 TONE Adjusts the tone. 0 – 100 COLOR Sets the sound color. 1, 2 Adjusts the volume. 0 –...
  • Page 8 Effect Types and Parameters [ PREAMP ] MS45OS This models the sound of the Marshall JTM 45 Offset. DRIVE Adjusts the gain of the input1. OFF - 100 Adjusts the gain of the input2. OFF - 100 Adjusts the volume. 0 - 100 BASS Adjusts volume of low frequencies.
  • Page 9 Effect Types and Parameters [ PREAMP ] FD DELUXE-R This models the sound of the Fender '65 Deluxe Reverb. DRIVE NORMAL INPUT Selects the input channel. VIBRATO GAIN Adjusts the gain. 10 - 100 Adjusts the volume. 10 - 100 BASS Adjusts volume of low frequencies.
  • Page 10 Effect Types and Parameters [ PREAMP ] RECTI DUAL This models the sound of the Mesa Boogie Dual Rectifier Orange Channel. DRIVE VNTG, MODE Sets the tone of the character. MDRN GAIN Adjusts the gain. 0 - 100 Adjusts the volume. 0 - 100 BASS Adjusts volume of low frequencies.
  • Page 11 Effect Types and Parameters [ PREAMP ] MATCH30 This models the sound of the Matchless DC-30. DRIVE GAIN1 Adjusts the gain of channel1. OFF, 0 - 100 BASS1 Adjusts volume of low frequencies in the channel1. 0 - 100 TRBL1 Adjusts volume of high frequencies in the channel1.
  • Page 12 Effect Types and Parameters [ PREAMP ] POLLEX With extreme drop-tuning, this amp delivers a heavy-metal Djent style of sound. DRIVE Recommended for slap-playing as well. GAIN Adjusts the gain. 0 - 100 Adjusts the volume. 0 - 100 BASS Adjusts volume of low frequencies.
  • Page 13 Effect Types and Parameters [ MODULATION ] ORANGE This effect varies the volume at a regular rate. TREMOLO TRI, TUBE, WAVE Sets the modulation waveform. DEPTH Sets the depth of the modulation. 0 – 100 RATE Sets the speed of the modulation. 0 –...
  • Page 14 Effect Types and Parameters [ MODULATION ] VIBRATO This effect automatically adds vibrato. DEPTH Sets the depth of the modulation. 0 - 100 RATE Sets the speed of the modulation. 0 - 50 TONE Adjusts the tone. 0 - 10 Adjusts the balance between original and effect sounds.
  • Page 15 DELAY Effect Types and Parameters [ MODULATION ] RING This effect produces a metallic ringing sound. Adjusting the "FREQ" parameter results in a MODULATOR drastic change of sound character. FREQ Sets the frequency of the modulation. 1 – 50 TONE Adjusts the tone.
  • Page 16 Effect Types and Parameters [ DELAY ] DUAL DELAY This effect combines 2 delays and is based on the Eventide TimeFactor DigitalDelay. TIMEA Adjusts the delay time of Delay A. 0 – 1490 TIMEB Adjusts the delay time of Delay B. 0 –...

  • Page 17: Time Sets The Delay Time

    Effect Types and Parameters [ DELAY ] FILTER DELAY This effect filters a delayed sound. TIME Sets the delay time. 1 - 2000 SHORT, Sets the delay time range. LONG, MODE When metronome is chosen, the delay time is synchronized to the tempo. REPEAT Adjusts the number of repeats.

  • Page 18: Reverb

    REVERB Effect Types and Parameters [ REVERB ] ROOM This reverb effect simulates the acoustics of a room. REVERB PRE DLY Adjusts the delay between input of the original sound and start of the reverb sound. 1 – 100 DECAY Sets the duration of the reverberations.

  • Page 19: Sfx

    Effect Types and Parameters [ SFX ] AUTOPAN This effect moves the sound image cyclically left and right. RATE Sets the speed of the modulation. 0 - 50 WIDTH Sets the width of the panning. 0 - 50 Adjusts the amount of waveform clipping. Higher values emphasize the auto-panning effect CLIP 0 - 10 more.

  • Page 20: Additional Tables

    3rd up 3rd up 4th up Major 5th up 6th up Table 2 [ LINE SELECTOR Signal Flow ] LINE SELECTOR ON ( NEXT EFFECT ) OUTPUT INPUT LINE SELECTOR OUTPUT INPUT OFF ( OUTPUT ) ©2023 ZOOM CORPORATION Z2I-5046-01...
