Cabinet Parts - KitchenAid KSRS25QDAL03 Parts List

CABINET PARTS

For Models: KSRS25QDWH03, KSRS25QDAL03
(White)
Illus. Part
No. No. DESCRIPTION
1 Cabinet (Not A
Serviceable Part)
2 2174748 Front Roller (2)
3 489456 Screw
4 981122 Roller (Rear) (2)
5 489427 Screw
6 2155013 Clip, Grille
7 489478 Screw
9 2156056 Shim
13 2171868 Shim, Hinge Top
14 489284 Screw
15 Hinge Cover
1129262 White
2150343 Almond
16 2171851 Hinge Bottom (2)
21 Filler, Wrapper
1110708 White
1110709 Almond
22 Grille
2155486 White
2155487 Almond
23 489367 Screw
30 2171865 Hinge, Top (2)
35 489464 Screw
41 940139 Drain Fitting
42 1108438 Tube, Extension
43 1108439 Clip, Drain Tube
47 2176140 Cover, Unit
49 Hinge Cover
1119787 White
1119789 Almond
52 549193 Clamp, Service
Cord
53 489084 Screw
54 2155311 Door Closer,
Lower Cam (2)
55 489483 Screw
2
(Almond)
4394426
