Cabinet Parts - KitchenAid KSSS42QMB01 Parts List

Illus. Part
No. No. DESCRIPTION
1 Literature Parts
2266808 Use & Care Guide
2307358 Energy Label
2306332 Service & Wiring
Sheet
2306424 Icemaker and
Ingredient Care
Center
Service Sheet
2302865 Main Control
Service Sheet
2266811 Installation
Instructions
2 Cabinet (Not A
Serviceable Part)
3 934011 Clip, Water Tube
4 1112023 Roller, Front &
Rear (4)
5 Support, Leveler
Assembly
2004506 Refrigerator Side
2004505 Freezer Side
6 2005006 Grommet, Wiring
7 2005007 Grommet,
Flexible
8 Cap, Water Filter
2186494W White
2186494B Black
9 2006442 Mounting Stud,
Grill
10 2004514 Clamp, Tube
11 2005783 Cam, Door Closer
12 2209022 Housing, Water
Filter

CABINET PARTS

For Models: KSSS42QMB01, KSSS42QMW01, KSSS42QMX01
(Black)
Illus. Part
No. No.
13 488500 Screw
14 3400525 Screw
15 2255709 Filter, Water
16 489399 Screw
17 3400230 Screw, Door Stop
18 2257644 Hinge (Top)
19 2005004 Grommet, Crossover
20 489464 Screw
21 2004994 Lock, Adjustable
22 2002903 Bushing
23 2209090 Clamp, Filter
24
2221242 Right Side
2004517 Left Side
25 486194 Screw
26 2005008 Retaining Ring,
27 1113227 Fastener (3)
28 2006342 Gap, Cover
29
2006780 Freezer Side
2006779 Refrigerator Side
30 2302876 Bushing,
31 8533913 Screw
(White) (Etched Aluminum)
Illus.
DESCRIPTION No.
32
33
Tube
34
Bushing
35
36
Housing
Spring, Door
Closure
37
38
39
Adjustable Bushing
40
41
Assembly (Bottom)
42
Hinge (Bottom)
44
Adjustable
45
46
47
48
49
2
Part
No. DESCRIPTION
Skirt−Grille,
Bottom
2209025W White
2209025B Black
Extension Arm,
Door Closer
2266882 Right
2266881 Left
Grille Bottom,
Front
2209428W White
2209428B Black
2005921 Screw
Bracket, Support
Base (Front)
2006616 Left
2006556 Right
1157158 Screw
2006617 Bracket, Support
Base (Rear) (2)
2006346 Washer
2266880 Bushing,
Extension Arm
1163283 Screw
2209709 Connector, Water
Switch, Rocker Arm
1118894 Refrigerator Door
Side
1115373 Freezer Door Side
2215938 Cover, Switch (2)
487415 Screw (4)
Bracket, Cover
2221097 Right
2221096 Left
2215612 Cover, Rear
2221070 Clamp, Tube
8199083
