Please read this manual first for correct installation and operation. This manual should be retained
for future reference. The information in this manual was current when published. The
manufacturer reserves the right to revise and improve its products. All specifications are therefore
subject to change without notice.
PRECAUTIONS
1.
Do not install the camera near electric or magnetic fields.
Install the camera away from TV, radio transmitter, magnet, electric motor, transformer,
audio speakers since the magnetic fields generate from above devices will distort the video
images.
2.
Never disassemble the camera nor put impurities in it.
Disassembly or impurities may result in trouble or fire.
3.
Never face the camera toward the sun.
Direct sunlight or severe ray may cause fatal damage to sensor and internal circuit.
4.
Keep the power cord away from water and liquid.
Touching the wet power cord may result in electric shock.
5.
Never install the camera in areas exposed to water, oil or gas.
Water, oil or gas may result in failure, electric shock or fire.
EVERFOCUS
1/3" Color Rugged Dome Camera

Operation Instructions

Model No.
EHD300N

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EHD300N and is the answer not in the manual?

Questions and answers

Related Manuals for EverFocus EHD300N

Summary of Contents for EverFocus EHD300N

  • Page 1: Operation Instructions

    Touching the wet power cord may result in electric shock. Never install the camera in areas exposed to water, oil or gas. Water, oil or gas may result in failure, electric shock or fire. EVERFOCUS 1/3” Color Rugged Dome Camera Operation Instructions EHD300N Model No.
  • Page 2 The most technically advanced EHD series are the newest vandal-resistant Color Rugged Dome Camera from EverFocus Electronics. The Color Rugged Dome Camera can withstand a blow from a 10-pound sledgehammer and has a built-in heater that allows for operation in low temperatures.

  • Page 3: Installation

    INSTALLATION 1. Loosen the 4 fix screws on the housing cover by using the attached wrench (Figure 1). Please pay attention not to damage the lens. Figure 1 2. Remove the camera. Vari-Focal Lens Locking Screws Figure 2 To remove the camera, first unplug the wire connection on the back of the camera. Then loosen the 2 locking screws on the camera base, push the camera base to the right (toward heater direction, as shown in Figure 2), remove the camera from the mounting base.
  • Page 4 3. Mounting the base. Side conduit entry Conduit plug setscrew Back conduit entry Mounting Setscrew Mounting Setscrew Mounting Setscrew Mounting Setscrew Figure 3 Attach the base to the wall or ceiling, fix the base by the 4 setscrews attached in the accessory pack.
  • Page 5 Back conduit entry (PF1/2) Side conduit entry (PF1/2) Figure 4 Caution: To prevent moisture leaking into the housing, apply an appropriate gasket or sealant around the conduit connection. 4. Wire Connection The camera comes with a conduit plug pre-installed in the PF 1/2 conduit entry on the side.
  • Page 6 Micro Switch for Alarm trigger V. Phase Adjustment VR Connect the power supply cable (12VDC/24VAC), video output and alarm output to the proper connectors shown as Figure 5. The V. Phase adjustment screw is located on the termination board. The vertical phase may require adjustment to synchronize the vertical phase of the camera with other camera in the system when it is to be used in the line-lock sync mode.
  • Page 7 Lens fixing Screws 140° 360° 60° Figure 6...

  • Page 8: Dip Switch Function

    DIP SWITCH FUNCTION BLC (Back Light Compensation) When BLC is turned on, the AGC, FL and IRIS operating point is determined by averaging over the center area instead of entire field-of-view, so that a dimly-lit foreground object at center area can be clearly distinguished from brightly-lit backgrounds.

  • Page 9: Simple Instructions For The Desiccant Pack

    SIMPLE INSTRUCTIONS FOR THE DESICCANT PACK Due to the camera lens blurred from the humidity inside the camera. The desiccant pack absorbs the humidity; please refer to the easy instruction as follows: 1. Adjust all settings first and place the desiccant pack on the horizontal rod, then bend the horizontal rod and fix it.

  • Page 10: Specifications

    SPECIFICATIONS Pickup Device Video Format Scanning System Picture Elements Horizontal Resolution 520TVL Sensitivity 0.4Lux/F=1.2 S/N Ratio Over 48dB (AGC off) Electronic Shutter Lens Type Auto Gain Control Flickerless Back Light Comp. Auto White Balance Gamma Correction Video Output Sync. Mode Weatherproof Vandal Resistant Power Source...
  • Page 11 CONTENT LIST Standard Accessories 1. Camera Unit 2. Operation Instruction (this document) 3. Accessory Pack 4. Waterproof Connector 5. Power & Video Cable Optional Accessory 1. Wall Mount Bracket (BA-EHD)
  • Page 12 415 Oser Avenue Unit S Hauppauge, NY 11788 TEL: 631-436-5070 FAX: 631-436-5027 www.everfocus.com Your EverFocus product is designed and manufactured with high quality materials and components which can be recycled and reused. This symbol means that electrical and electronic equipment, at their end-of-life, should be disposed of separately from your household waste.
