EverFocus EHD350/H2 Specifications

Color Cameras
EHD350
560 TVL High Resolution Color Vandal Dome Camera
Features
• 1/3" Sony Super HAD CCD with light sensitivity
of 0.5 Lux/F=1.2
• 560 TVL of horizontal resolution
• Revolutionary integrated 10-bit Digital Signal
Processor (DSP) delivers excellent picture quality
and sharp color images
• Vandal resistant with polycarbonate shell to
withstand intentional destruction
• Designed with 3-axis for angle viewing flexibility
• Heater triggers when temperature falls below
10°C / 50°F
• Built-in micro switch for alarm trigger
• Weatherproof IP66 rated
• Aluminum base with smoke color shell
• Ideal for any outdoor surveillance
Dimensions
130 mm / 5.1"
19
Outdoor Dome Cameras
98.8 mm / 3.9"

Specifications

Pickup Device 1/3" Sony Interline Transfer Super HAD CCD
Video Format NTSC or PAL
Picture Format 768 x 494 (NTSC) / 752 x 582 (PAL)
Horizontal Resolution 560 TVL
Video Output BNC 1.0 Vp-p, 75 ohm
Sensitivity 0.5 Lux/F=1.2
S/N Ratio Over 48dB (AGC Off)
Electronic Shutter 1/50 (1/60) ~ 1/100,000 sec.
Sync. Mode Line Lock/Internal Sync.
Flickerless On/Off switch
Backlight Comp. On/Off switch
Auto Gain Control On/Off switch
Auto White Balance Yes
Gamma Correction 0.45
Iris Level Adjustable
Lens Built-in vari-focal f=9~22mm / f=2.9~10mm
Dimensions (W x H x D) 130 x 98.8 x 130 mm / 5.1" x 3.9" x 5.1"
Operating Temp. -40°C ~ 50°C / -40°F ~ 122°F
Humidity 20% ~ 80% humidity
Power Source 12VDC/24VAC
Power Consumption With Heater:
24VAC: 20.5W max. / 12VDC: 11.5W max.
Without Heater:
24VAC: 6W max. / 12VDC: 4W max.
Weight 1.7 kg / 3.7 lbs.
Weatherproof IP66 rated
Vandal Resistant Yes

Ordering Information

EHD350/H2: 1/3" 560 TVL, Vari-focal lens f=9~22mm/F=1.6,
Smoke Shell w/Heater
EHD350/H3: 1/3" 560 TVL, Vari-focal lens f=2.9~10m /F=1.6,
Smoke Shell w/Heater
