EverFocus EHD150 User's Manual And Operation Instructions

EverFocus EHD150 User's Manual And Operation Instructions

1/3” b/w rugged dome camera
Hide thumbs Also See for EHD150:

Advertisement

Quick Links

Download this manual
EHD150
1
/
3
"
B
/
W
R
u
g
g
e
d
D
o
m
e
C
a
m
e
r
a
1
/
3
"
B
/
W
R
u
g
g
e
d
D
o
m
e
C
a
m
e
r
a
User' s Manual
and
Operation Instructions

Advertisement

loading
Need help?

Need help?

Do you have a question about the EHD150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EverFocus EHD150

Summary of Contents for EverFocus EHD150

  • Page 1 EHD150 ” ” User’ s Manual Operation Instructions...
  • Page 2 Meanwhile, please be advised that every step of operation must follow the instruction of this manual to keep EHD150 working under the best condition. Please notice that EverFocus will not be charged any claims or...

  • Page 3: Table Of Contents

    Table of Contents Safety Warning … … … … … … … … … … … … … … … … 1 Introduction… … … … … … … … … … … … … … … … … ..2 Specification…...

  • Page 4: Safety Warning

    1. Do not install the camera near electric or magnetic fields. Installed the camera away from TV, radio transmitter, magnet, electric motor, transformer, audio speakers because the magnetic fields generate from above devices will distort the video image. 2. Do not install the camera in the high temperature environment. Installed the camera away from stoves, or other heat generating devices as the high temperature could cause deformation, discoloration or other damages of the camera.

  • Page 5: Introduction

    It is perfect for all high-profile crime-prone applications such as building entrances, retail stores, and shopping malls. The extremely EHD150 is unquestionably one of the world's toughest cameras and is your best choice for vandal resistance.

  • Page 6: Specification

    Pickup device: Picture element: Horizontal resolution: Sensitivity: S/N ratio: Weatherproof ratings: Electronic shutter: IRIS Control: Auto gain control: Back light comp: Line Lock: Gamma correction: Video output: Power source: Power Consumption: Sync.mode: Dimension: Lens: Heater auto activated temperature: 10℃, Heater optional Operating temperature: Weight: Specification...

  • Page 7: Installation Instructions

    Installation Instructions 1. Loosen the 4 fix screws on the housing cover by using the attached wrench (Figure 1). Carefully uncap the housing cover as the direction shown below (Figure 2), please pay attention not to damage the lens. To remove the housing cover, push the hinges to the bottom of the bracket, the hinges can be easily removed from the bracket.
  • Page 8 3. Mounting the base. Side conduit entry Back conduit entry Mounting Setscrew Mounting Setscrew Attach the base to the wall or ceiling, fix the base by the 4 setscrews attached in the accessory pack. The dome is weighted 1.7kg, please make sure if the mounting is strengthened enough to support it, if not, please reinforce the mounting according to the environment.
  • Page 9 4. Wire Connection Micro Switch for Alarm trigger V. Phase Adjustment VR Connect the power supply cable (AC24V/DC12V), video output and alarm output to the proper connectors shown as Figure 6. The V. Phase adjustment screw is located on the termination board. The vertical phase may require adjustment to synchronize the vertical phase of the camera with other camera in the system when it is to be used in the line-lock sync mode.
  • Page 10 5. View Angel Adjustment The camera can be rotated 360°horizontally, and the vertical view angle is 140°(as shown in Figure 7). Adjust the proper camera view angel as needed. If a vari-focal lens is used, you may adjust the focus and zoom of the lens to bring the object in focus.

  • Page 11: Dip Switch Functions

    LL (Line-Lock) Off/On To select the sync mode between Internal Sync.(LL off) and Line-Lock (LL on). Set the line-lock off, the camera will synchronize to the internal time base. Set the line-lock on, the camera’s vertical synchronization can be driven by the AC signal in the power lines.
  • Page 12 BLC (Back Light Compensation) On/Normal When BLC is turned on, the AGC, ES and IRIS operating point is determined by averaging over the center area instead of entire field-of-view, so that a dimly-lit foreground object at center area can be clearly distinguished from brightly-lit backgrounds.
  • Page 13 IRIS Level Adjustment Brightness Level can be adjusted from the IRIS level VR while using the direct drive lens. ? Turn counterclockwise to L to get darker picture. ? Turn clockwise to H to get brighter picture. IRIS ALC Adjustment To select light metering method –...
  • Page 14 EverFocus Electronics Corp. Head Office: 12F, No.79 Sec. 1 Shin-Tai Wu Road, Hsi-Chi, Taipei, Taiwan TEL: 886-2-26982334 FAX: 886-2-26982380 http:// www.everfocus.com.tw USA Office: 2445 Huntington Drive, San Marino, CA, 91108 U.S.A. TEL: 1-626-844-8888 FAX: 1-626-844-8838 Toll free: 1-888-383-6287 or 1-888-EV-FOCUS http://www.everfocus.com...
