KitchenAid KSRS25FGBL04 Parts List page 8

MOTOR AND ICE CONTAINER PARTS
For Models: KSRS25FGWH04, KSRS25FGBL04, KSRS25FGBT04
(White)
Illus.
No.
1
2
3
4
7
8
9
10
11
14
18
19
20
21
22
23
24
25
26
27
28
30
31
32
33
34
35
37
38
39
40
44
45
46
(Black)
Part
No. DESCRIPTION
2183726 Bracket, Motor
2188385 Motor, Dispenser
2152713 Soleniod Assembly
2149100 Guide, Solenoid
2206501 Wiring Assembly,
Ice Dispenser
489399 Screw
2205716 Coupling, Motor
489478 Screw
2162085 Socket, Light
2196091 Ice Container
1119005 Spacer, Step (3)
1119007 Spacer, Flat (2)
1119006 Blade, Rotary
1119012 Blade, Rotary
1119013 Blade, Rotary
489235 Washer, Plain
1119009 Blade, Fixed (2)
2157405 Block, Blade
489229 Roll Pin
2196295 Auger
2209781 Drum
2171682 Floating Baffle
1119018 Nut, Bearing
2155231 Control Arm
1119020 Spring, Return
1119021 Retainer Clip, Rod
488886 Screw
2180348 Housing, Crusher
1119017 Deflector, Ice
489234 Washer, Plain
489236 Retainer Ring
2204321 Front Cover,
Ice Container
527949 Light Bulb
2171706 Light Lens,
Dispenser
8
(Biscuit)
4398871
